Agricultural Chaff Cutter Used for cutting green (dry) corn stalks, straw, straw and other crop stalks and pasture. Processing materials for breeding cattle, sheep, deer, horses, etc., but also processing cotton stalks, branches, bark, etc., for straw power generation, refining ethanol and paper making, wood-based panels and other industries.
SPECIFICATIONS FOR 9ZC chaff cutter
MODEL
POWER
CAPAPCITY
DIMENSION
9ZC-3
4KW/8HP
2-4T/H
1.0*0.6*1.4M
9ZC-5
5.5KW/10HP
4-6T/H
1.7*1.6*2.3M
9ZC-8
7.5KW/15HP
6-10T/H
2.1*1.6*2.8M
9ZC-10
15KW/20HP
10-15T/H
2.6*2.1*4.1M
9ZC-12
18.5KW/30HP
15-20T/H
2.6*2.2*4.1M
9ZC-14
30KW/40HP
20-30T/H
4.7*2.2*4.4M
Features of Our 9ZP Chaff Cutter Machine
* Could be driven by high quality Diesel Engine, Electric Motor (With Copper Wire), Petrol/Gasoline Engine for your different choice according to your local working site situations;
* Feeding Rollers in our Chaff Cutter Machine are made by Casting Iron with longer service life;
* Discharging size can be easily adjusted;
* Great Durability & Better Finishing;
* Output Nozzel With Adjustment of Direction of the Jet and Rotation of 360°;
* With high quality Blades which is specially for exporting with longer service life, and is 3 times service life than the ordinary blades;
* High-strength bolts are used for connection to provide safe and reliable operation;
* Steel frame structure, small volume, light weight, convenient to move;
* Unique adjustable speed gear box structure, easy and precise adjustment of grass length, reliable sealing, good lubrication;
* Advanced feeding and conveying mechanism is controlled by a switch, easy to switch;
* Our Chaff Cutter Machine is equipped with a safety device to prevent blade jamming, thus ensuring safety and reliability.
* Universal coupling is used as the grass roller transmission shaft to provide compact structure, flexible operation and convenient disassembly;
* The cover is made of thickened steel plates by continuous welding and adopts integrated die forming and pressed anti-fake brand to provide beautiful appearance and durable services;
* The data of steel thickness our Chaff Cutter Machine is higher than other suppliers; And our workmanship is much more delicate.
* OEM & ODM is accepted. And any customization is also accepted.
