1. Small size and easy to transport, could be loaded onto light truck or small trailer, four sets could be loaded into one 20GP container to save freight cost.
2. Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency
3. Famous brand hydraulic system parts ensure the stable quality.
4. equipped with double fuel filter to guarantee fuel purity to protect engine
5. boom deflexion design meet narrow work condition, reinforced rubber track to protect road
6. extend hydraulic line for various attachments.
7. comfort seat make operator easy to work.
8. Cabin with heater is optional.
9. Could be widely used in gardening, orchard, farming, basement reconstruction, waste residue carrying in coal washing factory, papermaking factory etc. and could replace 4~5 manpower.
Attachment price
Attachment | Narrow bucket 300 mm | Standard bucket 450 mm | Levelingbucket 800mm | Tilting bucket 800mm | Hydau Breaker | Auger 300 mm | Ripper | Quick hitch | Trailer |
|
|
|
|
|
|
|
|
|
|
Port of Loading: Qingdao
Payment term: By T/T
Lead time: 15 days after down payment.
Technical Specification
Engine
Model | Laidong 3TE25 18.4kW/2200rpm, | |
Type | 3 cylinders. Direct injection, water cooled, natural intake | |
Torque | 86/1760 Nm/rpm |
|
Displacement | 1.532 L |
|
Main Performance
Swing Speed | r/min | 10-12 |
Traveling Speed | km/H | 2.8 |
Grade ability | % | 70(35°) |
Traveling Tracking Force | kN | 15 |
Bucket Digging Force | kN | 11.5 |
Arm Digging Force | kN | 9.3 |
Hydraulic System
Hydraulic system working pressure | Mpa | 16 |
Hydraulic Pump | Gear Pump | AHWY |
Hydraulic pump flow | L/min | 2×22+8.8 |
Swing Motor |
| Eaton |
Traveling Motor |
| Eaton |
Fuel Tank Capacity | L | 26 |
Hydraulic Tank Capacity | L | 27 |
Overall Dimensions
Overall Length | mm | 3800 |
Overall Width | mm | 1050 |
Overall Height | mm | 2280 |
Ground clearance | mm | 485 |
Track length | mm | 1630 |
Track width | mm | 230 |
Undercarriage width | mm | 1050 |
Undercarriage ground clearance | mm | 235 |
Dozer Blade | mm | 1050×240 |
Operation parameters
Operation Weight | KG | 1800 |
Bucket Capacity | m3 | 0.06 |
Max. Digging Radius | mm | 3860 |
Max. Digging Depth | mm | 2050 |
Max. Digging Height | mm | 3370 |
Max. Dumping Height | mm | 2390 |
Max. Dozer Cutting | mm | 270 |
Max. Dozer Lifting | mm | 235 |
Boom Deflexion (Left/Right) | ° | 75/45 |
Tail Swing Radius | mm | 1125 |
Front Min. Swing Radius | mm | 1720 |
Attachments:
Shandong Tongwu Machinery Equipment Co., Ltd, is one of the professional total solution supplier of construction machinery and engineering machinery with its many years of production, sales and services. Tongwu keeps on growing with its reliable products and good service, Product coverage continues to expand, like Crawler excavator, Wheel excavator, Backhoe loader, Wheel loader, Skid steering loader, Truck concrete pump, Forklift, Road roller, Grader.
Tongwu sales network covers more than 20 provinces and cities, and exported to more than 50 countries, like Australia, Thailand, Indonesia, Brazil, Argentina, South Africa, Germany, England, France, Finland etc, several countries are with agent and distributors. Company adheres service first, quality-oriented management aim, got more and more good reputation these years.
