Новинка Лидер продаж панели-сэндвич Hysun из углеродного волокна плоский панели для фургон продажи контейнер
- Категория: Other Construction & Real Estate >>>
- Поставщик: Hysun,Eco,Building,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 3570.41 $* | 3749.44 $* |
| Aug-18-2025 | 3540.82 $* | 3717.60 $* |
| Jul-18-2025 | 2970.73 $* | 3119.75 $* |
| Jun-18-2025 | 3480.71 $* | 3654.31 $* |
| May-18-2025 | 3030.78 $* | 3182.70 $* |
| Apr-18-2025 | 3420.23 $* | 3591.98 $* |
| Mar-18-2025 | 3390.76 $* | 3560.88 $* |
| Feb-18-2025 | 3360.73 $* | 3528.71 $* |
| Jan-18-2025 | 3330.39 $* | 3497.89 $* |
Характеристики
Product Description
HYSUN flat pack container
HYSUN flat pack is a type of modular products designed from ISO shipping container and using steel frame and light weight wall
panels system.
Each Hysun flat pack consists of top roof frame, bottom chassis frame, 4 posts and 14 pcs exchangeable wall panels.
Hysun flat pack container can be flattened for easy transport. Hysun flat pack container has a lot of style that can be optional.
panels system.
Each Hysun flat pack consists of top roof frame, bottom chassis frame, 4 posts and 14 pcs exchangeable wall panels.
Hysun flat pack container can be flattened for easy transport. Hysun flat pack container has a lot of style that can be optional.
Specification
Roof Load | 1.5kn/Sqm |
Floor Load | 2.5kn/Sqm |
Switches | 1 Set with 2K |
Light | Tube Light or Ceiling Light, 2 PC |
Outlet | 2 PCS |
Distribute Box | 1 Set |
1.1 | Chasis | Frame: Q235 steel, GI steel with 4 corners Size: 6000mm/5896*2500mm*160mm. Paint:2 times primer and 2 times face paint. Default color: white. |
1.2 | Floor: 18mm fiber cement floor. Fireproofing: A. | |
1.3 | Flooring deco: 1.5mm vinly sheet | |
2.1 | Roof & Ceiling | Frame: Q235 steel, GI steel with 4 corners Size: 6000mm/5896*2500mm*170mm. Prulin: C80*40*20*1.4mm Paint:2 times primer and 2 times face paint. Default color: white. And color can be customzied. |
2.2 | Roof sheet: 0.45 PPGI sheet roof covering | |
2.3 | insulation: 100mm glass wool. | |
2.4 | ceiling: 0.4mm corrugated PPGI steel. | |
3 | Post | Q235,3mm GI steel. Anti-rust,panited. |
4 | External door | Steel door, size:970*2035*50mm, with AB lock. Door leaf steel thickness: 0.4mm Frame steel thickness: 0.6mm |
5.1 | External wall panel | 50mm EPS/rockwool sandwich panel with 0.35mm pre-coated GI steel sheet both side. |
5.2 | Internal wall panel | 50mm EPS/rockwool sandwich panel with 0.35mm pre-coated GI steel sheet both side. |
6.1 | Window | PVC sliding window, size：930*1100mm, Glass: 5mm With steel security bar |
6.2 | Toilet Window | PVC sliding window, size: 600*600mm, ready in the panel. Glass: 5mm |
7.1 | Electrical system | Light-1: fluorescent lamp with double tube. |
7.2 | Socket: 10A 5 holes socket*4,16A A/C socket*1 CE,AS/NZ,UL.available | |
7.3 | Switch: 1K switch | |
7.4 | Distrubute box: 1 set | |
7.5 | Power connecting plug: 220V，50Hz,3P32A. Q'ty: 1 set | |
8.1 | Decoration strip | Wall strip: PVC. White |
8.2 | Ceiling trim: PVC.White | |
8.3 | Floor trim: PVC. | |
9.1 | Joint Accessories | Bolt: M10, 50 pcs. |
9.2 | Flooring cover:PPGI steel sheet | |
9.3 | Post cover: steel sheet | |
9.4 | watertight rubber sheet: for waterproofing work for the place combined |
Details Images
More Applications
More options
Hysun is a trun key house solution supplier. We also offer many other items on option. Pls feel free to contact us if any interest or any demand.
Soft Reminder:
1. All hysun container houses are available to be customized.
2. The price and package in the list is only for refer and the final price would offer together with drawing and final material.
Pls contact us for detail material list and price.
Soft Reminder:
1. All hysun container houses are available to be customized.
2. The price and package in the list is only for refer and the final price would offer together with drawing and final material.
Pls contact us for detail material list and price.
Our Advantages
Modular: All material have been ready in the factory. 90% work ready.
Fast: 3-4 hours for installation by 4 workers.
Green: None construction waste caused. Can use several times
Free space: can combine to big space in vertical and horizontal, also available in load to 3 layers building
Fast: 3-4 hours for installation by 4 workers.
Green: None construction waste caused. Can use several times
Free space: can combine to big space in vertical and horizontal, also available in load to 3 layers building
1. Low cost & easy assemble: time saving and labor saving.
2. Flexible layout,portable & fold-able .
3. Fast construction and easy installation: removable,can be moved to anywhere.
4. Nice appearance and Long using lifespan: up to 15-200 years.
5. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.
2. Flexible layout,portable & fold-able .
3. Fast construction and easy installation: removable,can be moved to anywhere.
4. Nice appearance and Long using lifespan: up to 15-200 years.
5. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.
Hysun Service
As a professional manufacturer in prefabricated house, Hysun provide the following services with professionalism and great sense of responsibility.
1. Customized drawings design
2. Competitive quotations
3. Professional suggestions for cost effective solution
4. Project installation instruction or supervision
We also guantee:
Product Quality
Hysun offer 1 year gurantee for Hysun high-end container house. All product should be checked quality from raw material, during production to before load. We make sure every parts arrive to your hand are perfect.
On-time Shipment
Hysun also guarantee on time delivery time under our experienced workers and modern machine under good management.
All steel part and materials shall be packed carefully under full protection.
Company Profile
HYSUN Company View
HYSUN ECO BUILDING CO.,LTD is specialized in container house solution and steel structure since 1993.
HYSUN become an expert in container house R&D, produce and install under our full experience design team, skilled workers and advanced equipment.
Based on the plants in Shanghai, Chengdu, and Weifang, HYSUN offers the modified container, flat pack container, and expandable container for commercial use such as bar, kitchen, restaurant, tourist and hotel, accommodation, office, health center and so on.
HYSUN has sent the houses to 44 countries. Our main market is Australia, Europe, South America and North America.
HYSUN offers the service from design to the installation guide. Meantime, Hysun offers a 1-year warranty and a 5-year guarantee for our house.
HYSUN become an expert in container house R&D, produce and install under our full experience design team, skilled workers and advanced equipment.
Based on the plants in Shanghai, Chengdu, and Weifang, HYSUN offers the modified container, flat pack container, and expandable container for commercial use such as bar, kitchen, restaurant, tourist and hotel, accommodation, office, health center and so on.
HYSUN has sent the houses to 44 countries. Our main market is Australia, Europe, South America and North America.
HYSUN offers the service from design to the installation guide. Meantime, Hysun offers a 1-year warranty and a 5-year guarantee for our house.
Office
Udana, Sri Lanka
We got a container school from Hysun. It is really so convenience for us. The containers is ready electricity and plumpbing, we also get the perfect furniture and all related fitiings. We got a turn-key solution.
Gustavo Falciroli, Australian
I really love the house. I have passed my hand drawing and HYSUN make it become real. It is exactly what I want, 1 bedroom, 1 saloon and equipment with toilet room and kitchen. I put the house in my garden, my kids like staying inside.
Gerald Gimeno, Romania
They are the best flat pack containers we've gotten. We have looked for 20ft container in SOC ship until we found Hysun. All details are prefect and our clients are satisficed with the houses. Meantime, Hysun can do different size and can offer so fashion design in short time.
Basil Azim, America
I have worked with Hysun 4 years. Before we worked in tiny house, Hysun offered some small house for us. And now we are working in booths, bars, restaurants, hotels. We design together and work as a team. We like the quality, especially the paint. Nobody like to spend more in after-sale. The first house we got from Hysun is also in good condition.
We got a container school from Hysun. It is really so convenience for us. The containers is ready electricity and plumpbing, we also get the perfect furniture and all related fitiings. We got a turn-key solution.
Gustavo Falciroli, Australian
I really love the house. I have passed my hand drawing and HYSUN make it become real. It is exactly what I want, 1 bedroom, 1 saloon and equipment with toilet room and kitchen. I put the house in my garden, my kids like staying inside.
Gerald Gimeno, Romania
They are the best flat pack containers we've gotten. We have looked for 20ft container in SOC ship until we found Hysun. All details are prefect and our clients are satisficed with the houses. Meantime, Hysun can do different size and can offer so fashion design in short time.
Basil Azim, America
I have worked with Hysun 4 years. Before we worked in tiny house, Hysun offered some small house for us. And now we are working in booths, bars, restaurants, hotels. We design together and work as a team. We like the quality, especially the paint. Nobody like to spend more in after-sale. The first house we got from Hysun is also in good condition.
Packing & Delivery
6 Units/40HQ
The first picture is plan A: Top and bottom done, wall board in the middle, with no fumigation plate sealed. Size: 5896*2500mm
The second picture is plan B: Top and bottom fixed, wall panels, doors, Windows and other separate placed, one 40HQ installed 6 sets. Size: 6000*2500mm
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1. who are we?
We are based in Sichuan, China, start from 2016,sell to South America(20.00%),Northern Europe(15.00%),Mid East(15.00%),Domestic Market(15.00%),North America(15.00%),Eastern Europe(12.00%),South Asia(8.00%).
We are based in Sichuan, China, start from 2016,sell to South America(20.00%),Northern Europe(15.00%),Mid East(15.00%),Domestic Market(15.00%),North America(15.00%),Eastern Europe(12.00%),South Asia(8.00%).
There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
container house,martime container,modified container,expandable container,flat pack container
4. why should you buy from us not from other suppliers?
1. Since 1993 focus in steel structure 2. Powerful factory with modern machine
3. Professional Team in design and sale
4. Full Service from design to after-sale
5. Quality Control on whole production
5. what services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW；
Accepted Payment Currency: USD, EUR;
Accepted Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow;
Language Spoken: English, Chinese, Spanish
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
container house,martime container,modified container,expandable container,flat pack container
4. why should you buy from us not from other suppliers?
1. Since 1993 focus in steel structure 2. Powerful factory with modern machine
3. Professional Team in design and sale
4. Full Service from design to after-sale
5. Quality Control on whole production
5. what services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW；
Accepted Payment Currency: USD, EUR;
Accepted Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow;
Language Spoken: English, Chinese, Spanish
