Экспозиционный стол для большой трафаретной печати УФ-шкаф экспозиционный

Экспозиционный стол для большой трафаретной печати УФ-шкаф экспозиционный

Категория: Pre-Press Equipment >>>
Поставщик: Dongguan,Ruida,Machinery,And,Equipment,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	0.46 $*	0.10 $*
Aug-19-2025	0.68 $*	0.7 $*
Jul-19-2025	0.20 $*	0.45 $*
Jun-19-2025	0.26 $*	0.54 $*
May-19-2025	0.60 $*	0.30 $*
Apr-19-2025	0.68 $*	0.87 $*
Mar-19-2025	0.48 $*	0.4 $*
Feb-19-2025	0.89 $*	0.91 $*
Jan-19-2025	0.61 $*	0.17 $*

Характеристики

MD1201 Big UV exposure unit with Vacuum lamp for screen printer

Key Feature:

Power : 220V/2000W
Light : UV Light
Glass Dimension : 900 x 1200mm;
Exposure Area : 700mm×1000mm;
Vacuum degree : -0.1~ -0.08mpa.
Net Weight : 100KG
Gross weight : 140KG
polywood case Package:128*101*103cm

Product Summary:

Used in the filed of plate-making such as pad plate, screen plate, hot stamper plate, resin plate. when you put the film onto the plate into UV exposure machine, start it, the emulsion on the plate will appear a unseen imagine. this is important process on all plate-making technology.flexibility Rubber Film ensure Film contact compactly with surface of slik when vacuum state.

DESCRIPTION This screen printing exposure unit series are widely used in the filed of plate-making for screen plate, .
FEATURES 1. Choose high quality metal halid lamp. keep long life. 2. Reflect cover made by resist aging materials. 3.It can reach the vacuum state instantly, and save time for printing 4. Exposal time auto adjustment and controlling. 5. High vacuum degree, easy to transfer and copy fine lines 6. Automatic door of lamp shut off and turn on when exposure and finish ensure long life of lamp 7. High toughness Rubber Layer ensure Film closely cover with frame 8. We also can supply the different size of screen printing machine according to customer's requirement
Announcements 1. Long time will not work, pull the plug. 2. Finished working after a version, according to the stipulation time open and close. 3. If screen frame with water, don't use vacuum, otherwise the inhaled water will be rusted the vacuum pump. 4. Keep the worktable neat and dry, with soft and delicate cloth to clean after finishing work. 5. Keep in ventilated and dry place, far away corrosion items. 6. Do not keep it in high heat and humidity place. 7. Once turn off the lights, should be in a given time after 5 minutes (that is after cooling tube) to turn on the light, otherwise, it will reduce the working time of lamp. 8. light hand should press 1 second, don't long hold, it's too easy to burn out trigger

DESCRIPTION

This screen printing exposure unit series are widely used in the filed of plate-making for screen plate, .

FEATURES

1. Choose high quality metal halid lamp. keep long life.

2. Reflect cover made by resist aging materials.

3.It can reach the vacuum state instantly, and save time for printing

4. Exposal time auto adjustment and controlling.

5. High vacuum degree, easy to transfer and copy fine lines

6. Automatic door of lamp shut off and turn on when exposure and finish ensure long life of lamp

7. High toughness Rubber Layer ensure Film closely cover with frame

8. We also can supply the different size of screen printing machine according to customer's requirement

Announcements

1. Long time will not work, pull the plug.

2. Finished working after a version, according to the stipulation time open and close.

3. If screen frame with water, don't use vacuum, otherwise the inhaled water will be rusted the vacuum pump.

4. Keep the worktable neat and dry, with soft and delicate cloth to clean after finishing work.

5. Keep in ventilated and dry place, far away corrosion items.

6. Do not keep it in high heat and humidity place.

7. Once turn off the lights, should be in a given time after 5 minutes (that is after cooling tube) to turn on the light, otherwise, it will reduce the working time of lamp.

8. light hand should press 1 second, don't long hold, it's too easy to burn out trigger

Package:

Use very stong and safety polywood case package:

screen printing package-8

Our Factory

Key Feature:

• Mode : MD1202 Vacuum screen exposure machine

• Power: 220V/50Hz, 2000W
• Light source:UV light
• Glass Dimension : 900 x 1200mm
• Glass thickness : 10mm
• Max Frame dimension : 750×1050mm
• Vacuum degree : 0.05mpa.
• Machine Demension : L1200 x W900 xH900mm
• Net Weight :120KG
• Gross Weight : 150KG
• Packing Box Size : L1300*W1000*H1100mm

Working Principle
Screen printing screens are coated with a light sensitive emulsion using a scoop coater. When the emulsion is dry, place a positive print of your image on the screen. Once you burn the screen, the emulsion that did not get any UV will wash out of the screen exposing the tiny pin holes. The surrounding areas that were exposed to UV will be cured. Hence the ink will pass through screen onto your substrate.
Main Features
1. Rational design & easy operation: based on humanity and practicality principles, with the elaborate designed table type structure, it’s much easier for screen exposure with high precision. 2.Independement settings of vacuum and exposure time with automatic memory function: The vacuum time and exposure time can be set up separately just according to actual requirements (setting ranges: 0-999 seconds); When exposure is finished, the power supply of the lamp will be automatically cut off, it will deflate and beep by itself, then please turn it off. When you need exposure again, just connect the power supply, then it will work automatically according to your former settings because of its automatic memory function. 3.Oilless vacuum pump with high quality is durable with no need for oil injection. 4. 8 pieces of special UV exposure lamps will guarantee a precise and even exposure effect. 5. The high strength toughened glass (thickness: 0.24”/6mm) is with high press resistance and not easily scratched. Besides, once broken, it will turn into pieces without sharp edges to avoid user’s injury. 6.All-metal construction & elegant appearance with advanced electrostatic paintings, easy to clean and no rust. 7.Excellent packing in study wooden case as a whole will guarantee a easy and safety transportation.
