Кабель электропитания 0,75-10 мм2, Электрический кабель
US $0.45-$0.55
UL1015 провод 12AWG ПВХ Тонкий изолированный медный
- Категория: >>>
- Поставщик: Haiyan,Hanker,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.31 $* | 0.26 $* |
| Aug-17-2025 | 0.58 $* | 0.59 $* |
| Jul-17-2025 | 0.91 $* | 0.93 $* |
| Jun-17-2025 | 0.93 $* | 0.96 $* |
| May-17-2025 | 0.31 $* | 0.69 $* |
| Apr-17-2025 | 0.97 $* | 0.2 $* |
| Mar-17-2025 | 0.42 $* | 0.55 $* |
| Feb-17-2025 | 0.48 $* | 0.90 $* |
| Jan-17-2025 | 0.28 $* | 0.8 $* |
Характеристики
Productor Name:AWM 758 UL1015 10AWG Tinned copper electronic wire
Application:
- For general purpose on internal wiring Of electronic and electrical equipment.
Product Description:
- Rated temperature 105℃
- Rated voltage: 600 volts.
- Reference Standard: UL 758 & CSA C22.2 No. 210, JQA - F - mark.
- Solid or Stranded, tinned or bare copper Conductor, 26-10 AWG
- Color-coded PVC indulation (RoHs Free)
- Uniform thickness of wire to ensure easy Stripping and cutting
- Passes VW-1, FT1 & -F- flame test
| UL Style & C-UL Type | Conductor | Insulation Thickness | Overall Diameter (Approx) | Standard Put-Up | Conductor Resistance at 20℃ (Maximum) | ||
| AWG | No./mm. | mm | mm | Ft/coil | M/coil | Ohm/km | |
| UL 1015 LA (Stranded) | 26 | 7/0.160 | 0.76 | 2.05 | 2000 | 610 | 150 |
| 24 | 11/0.160 | 2.20 | 2000 | 610 | 94.2 | ||
| 22 | 17/0.160 | 2.40 | 2000 | 610 | 59.4 | ||
| 20 | 21/0.180 | 2.55 | 2000 | 610 | 36.7 | ||
| 18 | 34/0.180 | 2.80 | 2000 | 610 | 23.2 | ||
| 16 | 26/0.254 | 3.10 | 2000 | 610 | 14.6 | ||
| 14 | 41/0.254 | 3.50 | 1000 | 305 | 8.96 | ||
| 12 | 65/0.254 | 3.90 | 1000 | 305 | 5.64 | ||
| 10 | 105/0.254 | 5.10 | 1000 | 305 | 3.54 | ||
Mark:
E493390  AWM 1015 **AWG 80℃ 300V VW-1  AWM Ⅰ A 80℃ 300V FT1 HANKER |
Packaging & Shipping
1000FT/305 meters coil or plastic drum
2000FT/610 meters coil or plastic drum
Certificate:
More Product:
UL 1007 UL 2464
Other type product:
Car Popwer Cable Speaker cable Lan cable
Coaxial cable Telecom cable
Factory:
Workflow:
| All products are in strict accordance with the standards of production and inspection processes in order to ensure stability of product quality |
Exhibition:
FAQ
1. Q: I need your price list of all your products, do you have a price list ?
A: We do not have a price list of all of our products. Because we have so many items,and it’s impossible to
mark all of their price on a list.And the price are always changing because of the producing cost.If you
want to check any price of our products, please feel free to contact us.We will send offer to you soon!
2. Q : Can you make customized products and customized packing?
A: Yes.We made a lot of customized products for our customer before.(mainly wire harness)
And we made many moulds for our customers alread.
About customized packing,we can put your Logo or other info on the packing.There is no
problem.Just have to point out that ,it will cause some additional cost.
3. Q: Can you provide samples ? Are the samples free ?
A: Yes,we can provide samples.Normally,we provide 1-3pcs free samples for test or quality checking.
But you have to pay for the shipping cos.If you need many items, or need more qty for each item,
we will charge for the samples.
