Product Description

Defi5 Manufacturers Portable Biphasic AED Automated External Defibrillator

Automatic External Defibrillator features include:

Three-step defibrillation process

Two-button operation

Extensive voice and visual prompts for the operator

Biphasic energy output

Physical

Category Specification

Dimensions 303 x 216 x 89 mm

Weight 2.0 kg

Operating Temperature 0℃ to 40℃

Operating Humidity Relative humidity between 30% and 95% (non-condensing)

Storage Temperature -20℃ to 55℃

(without battery)

Storage Humidity Up to 93% (non-condensing)

(without battery)

Electrical Isolation

Power Unit operates on internal battery only

External Electrical Connections No external devices are attached to the unit

Risk Current Category Internally powered equipment with defibrillator-proof BF type patient applied part (as per definition of IEC 60601-1 standard)

Defibrillator

Biphasic Truncated exponential Less than 30 seconds

150, 150, 200J Less than 35 seconds

10 sec. to 150J Less than 25 seconds

15 sec. to 200 J 22 audible prompts

9 sec. LED prompts

Two buttons - On/Off, Shock

±15% into any impedance from 25 to 175Ω .20Ω to 200ΩWaveform details

The table below provides details of the biphasic truncated exponential waveform delivered by the DEFI5 (set to 200J) when connected to resistive loads of 25 through 175 Ohms. The waveforms are characterized by typical values for peak current (Ip), duration of the first output phase, and duration of the second output phase. Values are within 10%.

Output Energy(J)	Patient Impedance(Ω)	I p1 (Amps)	I p2 (Amps)	Phase1 (ms)	Phase2 (ms)	Interval (ms)
200	25	53.6	36.0	5.5	3.3	0.7
	50	27.8	17.5	10.9	6.6	0.7
	75	18.2	12.0	16.3	8.9	0.7
	100	13.4	9.0	19.7	9.6	0.7
	125	10.5	7.2	20.5	11.2	0.7
	150	8.6	6.0	21.6	10.4	0.7
	175	8.2	6.1	21.8	11.2	0.7
