Самая низкая цена уличный спринклер для воды тележка дороги автоцистерна Dongfeng

Vehicle parameters

Vehicle Model

EHY5060GSSE

Vehicle Brand

HUAYI

Overall dimensions

5980X1980X2180mm

Curb weight

2950kg

Tank dimensions

3500×1720×1150mm

Tank volume

5000L

Chassis parameters

Chassis model

EQ1060TJ20D3

Chassis brand

DONGFENG

Overall dimensions

5820x1940x2080mm

Wheel base

3300mm

Front/rear wheel track

1506/1466mm

Front/rear suspension

1032/1488mm

Approach/departure angle

19/15°

Maximum speed

80km/h

Chassis Manufacturer

Dongfeng Automobile Co.,Ltd

Cab

Configuration

Single row cab,allowable 3 passengers

Color

White,other color is optional

Engine

Model

CY4102-C3F

Emission

Euro 3

Type

in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine

Rated power

95hp,rated power speed 3200rpm

Displacement

3856ml

Bore x stroke

102x118mm

Manufacturer

Dongfeng Chaoyang Diesel Power Co. Ltd.

Tire

Size

7.00-16 nylon tire

Number

6+1 nos

Fuel tank

100L,steel

Front axle

2.0T

Rear axle

4.0T

Drive form

4X2

Rated voltage

24V,DC

Transmissions

5 speed forward 1 reverse.

Steering wheel

Left hand drive

Selective configuration

Air Conditioner,steel wire tire,power assisted steering

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Water tank structure parameters

Tank dimensions

3500×1720×1150mm

Tank volume

5000L

Tank material

Carbon steel

Tank thickness

4/5mm

Nozzle sprinkling width

≥14m

Range of water cannon

≥28m

Suction height

≥7m

Color and Logo

Optional

Standard configuration

Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.

Selective configuration

Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights

Extended model

water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.
