Натуральный нагревательный элемент для электрического вентилятора 220/230
- Категория: Industrial Heater >>>
- Поставщик: Wenzhou,Natural,Automation,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.38 $* | 0.98 $* |
| Aug-18-2025 | 0.48 $* | 0.85 $* |
| Jul-18-2025 | 0.62 $* | 0.76 $* |
| Jun-18-2025 | 0.94 $* | 0.26 $* |
| May-18-2025 | 0.94 $* | 0.2 $* |
| Apr-18-2025 | 0.48 $* | 0.3 $* |
| Mar-18-2025 | 0.41 $* | 0.47 $* |
| Feb-18-2025 | 0.96 $* | 0.80 $* |
| Jan-18-2025 | 0.51 $* | 0.30 $* |
Характеристики
Products Description
NTL 400 | ||
Operating voltage | 230VAC or 120VAC | |
Heating element | PTC resistor-temperature limiting | |
Temperature safety cut-out | to protect against overheating in case of fan failure, automatic reset | |
Heater body | max. +75°C (500W) | |
Axial fan, ball bearing | Airflow, free flow 45m³/h (50Hz) or 54m³/h (60Hz) service life 50,000h at +25°C (+77°F) | |
Connection | internal connection terminal 1.5mm² with strain relief, clamping torque 0.8Nm max. | |
Connection casing | plastic according to UL94 V-0, black | |
Mounting | vertical airflow (air outlet up) | |
Operating/Storage temperature | -45 to +70°C (-49 to +158°F) | |
Operating/Storage humidity | max. 90% RH (non-condensing) | |
Protection type/Protection class | IP20 / I (earthed) | |
Note | other voltages on request | |
* Compact Design
* Clip fixing
* Long service life
* Temperature safety cut-out
* Clip fixing
* Long service life
* Temperature safety cut-out
Compact fan heater prevents formation of condensation and frost. The integrated high-performance axial fan provides
an evenly distributed interior air temperature in enclosures with electric/electronic components.
an evenly distributed interior air temperature in enclosures with electric/electronic components.
