Description:
As a new type of Ultrasonic Homogenizer, it enjoys complete functions, novel appearance and reliable performance. It has a large-screen display and concentrated control by a central computer. The ultrasonic time and power can be set accordingly. Besides, such functions as sample temperature display, actual frequency display, computerized tracking and automatic trouble warning can all be displayed in the large LCD screen.



Features:

1. Using PWM control switcher, power adjustable


2. Novel design, Complete-function, High efficiency and low cost laboratory homogenizer


3. Reliable ability, Large LCD digital display, Fully microprocessor controlled and completely programmable


4. Auto-tuning for convenience use and optimal processing efficiency


5. Temperature indicator and controller ,Time setting


6. Power-emitted display for accuracy and repeatability, Variable power output, 0-950 watts


7. Actual frequency display and computerized tracking


8. Automatic trouble warning system


9. Integrated Sound Abating Chamber to reduce cavitational sound emitted during processing

Main Technical Parameters:

MODEL	UH-IID
Frequency	20-25KHz
Power	950W
Accompany(Φ)	Φ6mm
Optional Tip (Φ)	Φ2, 3, 10, 15mm
Processing Volume	0.5-600ml
Duty Ratio (%)	0.1-99.9%
Display	7’’ LCD touch
Data	50 groups
Temperature alarm	0-99 °C
Time alarm	Yes
Overload alarm	Yes
Timer	0-999min
Work way	Continues/Gap
Supply	220/110V  50Hz/60Hz
Power supply chassis Size and Weight	400*280*220mm; 12.2 Kg
Mainframe Weight	14.3kg
Speaker compartment  Size & weight	275*250*480 (mm), 8.04 Kg
Packing Size	534*295*435mm
