Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Sep-16-2025 | 53550.95 $* | 56228.23 $* |
Aug-16-2025 | 53100.37 $* | 55755.92 $* |
Jul-16-2025 | 44550.21 $* | 46778.3 $* |
Jun-16-2025 | 52200.35 $* | 54810.33 $* |
May-16-2025 | 45450.15 $* | 47723.3 $* |
Apr-16-2025 | 51300.22 $* | 53865.8 $* |
Mar-16-2025 | 50850.58 $* | 53393.83 $* |
Feb-16-2025 | 50400.6 $* | 52920.13 $* |
Jan-16-2025 | 49950.51 $* | 52448.6 $* |
Model Parameters | CV 1000 | CV 2000 | CV 3000 | CV 5000 | CV 10000 | CV 20000 | ||||||||
Daily Output (T/24h) | 1 | 2 | 3 | 5 | 10 | 20 | ||||||||
Compressor Power (kw) | 4.34 | 7.88 | 10.58 | 21 | 42 | 73.5 | ||||||||
Fan Power for Cooling Tower (kw) | 0.18 | 0.37 | 0.56 | 0.75 | 1.5 | 2.2 | ||||||||
Cooling Pump Power (kw) | 1.1 | 1.5 | 1.5 | 2.2 | 4.0 | 5.5 | ||||||||
Unit Size (mm) | Length | 1800 | 1630 | 1980 | 2890 | 5730 | 7100 | |||||||
Width | 1000 | 1600 | 1630 | 1780 | 1780 | 2250 | ||||||||
Height | 1700 | 1706 | 1860 | 1860 | 2130 | 2300 | ||||||||
Unit Net Weight (kgs) | 800 | 1000 | 1200 | 1600 | 3000 | 5000 | ||||||||
* Size of cub ice: 22*22*22 mm / 29*29*22 mm / 38*38*22 mm * Compressor brand: Bitzer / Frascold; Refrigerant: R22/R404A; Cooling method: Water Cooling / Air Cooling; * Power supply: voltage 380V /3P/50Hz (for non-standard voltage, unit configuration needs to be calculated separately.) * Operating conditions: T (water supply); 20℃, T (ambient): 32℃, T (condensing):40 ℃, T (evaporating):-10℃。 |
item | value |
Applicable Industries | Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Construction works , Energy & Mining, Food & Beverage Shops |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Local Service Location | Philippines, Malaysia |
Showroom Location | Philippines, Malaysia |
Condition | New |
Place of Origin | China |
Brand Name | CBFI |
Ice Shape | Other |
Voltage | 380V-3P-50Hz |
Power | 19.61 |
Dimension(L*W*H) | 2860mm*1700mm*1800mm |
Weight | 1600kgs |
Certification | ce |
Warranty | 1 Year |
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support | |
Key Selling Points | Automatic |
Ice storage capacity | 1000kg |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Marketing Type | Ordinary Product |
Warranty of core components | 1 Year |
Core Components | Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC |
Cube ice size | 22mmx22mmx22mm or 29mmx29mmx22mm |
Compressor | Bitzer/Copeland |
Control | PLC program control |
Display | Electrical display |
Machine body material | Stainless steel |
CV series capacity | 1000kg to 20000kg |
PLC | Germany brand simens |
Electrical box | Korea brand LG |
Expansion valve | Denmark brand Danfoss |
Solenoid valve | Italy brand Castle |
1. Whether can adjust the tube ice size?
Tube ice Diameter:22mm, 28mm.35mm
Tube ice lenght: 24-45mm
Tube ice inner size: 3-5mm
2. Do you have engineer in our country to install the machine ?
We could introduce the local engineer to you install the machines.
3. What shall we do if there is any machine's malfunction?
You could see any malfunction reason from the touch screen and we could supply you the solution accordingly.
4. Could you send your engineer from China to install the machines?
Yes, we could send you enigneer from China to install your machine, you will be responsible for the accommodation and the installation cost.
5. Whats the deliver time of your machine?
1~5ton, 30 days since the deposit arrived at our account, 5~20 ton, 45 days. (based on the electricity 380V/50Hz/3p, some special
design lead time will be longer)
6. Whats the payment method you accept?
Pay via Alibaba, T/T, LC, In Cash, Western Union, Money Gram. 30% deposit, balance should by paid before shipping.
7. How long the warranty for machine I buy?
12 months since the deliver date.
8. how to install the machine ?
a. manual book and video will be provided to guide you how to install the machine, and also our service online
b. technician can be sent to customer's site too, while the round ticket, visa, accommodation is at customer cost, Installation
fee 100 USD/day/person. Local labors are necessary to support our technician's work
