Высококачественное 12 В автоматическое универсальное свинцово-Кислотное зарядное устройство для

Features:
1.\tThis product is applicable to the 12V or 24V lead acid batteries,including added-water storage batteries ,starting batteries and maintenance-free batteries.
2.\tIt uses the advanced microcomputer managemental system to multi-protect your batteries.
3.\tIt uses the pulse width modulation(PWM) technology to automatically charge the batteries through a 4-stage charging cycle.
4.\tGuarantee that the batteries won’t damage even if the batteries sulfided, storaged gas,or lost water.
Specification:
1.\tThis device is widely used in 12V or 24V batteries (3AH-400AH).
2. Use the advanced pulse width modeling technologies, full microcomputer controlled charging modulation to display ,constant currents, constant voltage, trickle, floating charge.
3. The microcomputer digital pulse to repair can immensely increase the lifespan of your batteries.
4. Use the advanced microcomputer management system to multi-protect the batteries.
5. This product has the function which can test currents, you can depend on the charging radio of 10:1 ,according to the different capacities of the batteries ,test the currents of the batteries.
6. Module: intelligent ,fast charge ,full-microcomputer digital controlled ,no need to look after as it is working.
7. Real display the batteries’ voltage , currents .and display the testing currents ,the fan intelligent moving.
The Specification About The Charging Mode:
A. Intelligent Charge Mode: While you start the charger ,it will be defaulted into the intelligent charge mode.Each one time that you charge ,this product will scan and test the battery. As test the battery, the screen will display the circle which has the four-cells will be scanning twice. After test the status of the battery .it will module into charging (repair ,maintenance or maintain.

B. Fast Charge Mode:Press the modulation switch will come into the fast charge mode, it will display the real charging status.
The Functional Description:
When the charging rate displays 25%、50%、75%、100% ,it shows the charging rate of power.This product use the full-microcomputer screen display, the fan will intelligently start,sometimes fast sometimes slowly that indicates on pulse charging, and has the power-switch of out-connection to control. And it can display the real charging voltage and current of your batteries.It has one switch which can convert the intelligent or fast charge modulation,while you convert the modulation ,it will has the alertness .When the battery capacity is going to over-low ,it will alert for the over-low voltage,and the battery circle which has the four-cells within 25%、50%、75%、100% are flashing simultaneously indicates that your battery voltage is over-low.After the battery is repaired by the charger,it will display the normal recharging rate again.While the battery is full-charged,it will have a voice indication,and the beep device will make a sound each one minute shows that your battery has full-charged already.This product also can do both modulation and modulating display of current.You can convert the charging current according to your battery capacity, for the batteries which is under 30AH ,you should convert under 8A current to charge; for the batteries which is 40AH to 100AH, you should convert on 10A current to charge; for the batteries which is 200AH,you should convert on 15A current to charge;for the batteries which is under 300AH,you should convert on 25A current to charge. When the battery is full-charged, the screen displays 14V to 14.5V mean your batter is good, if it displays 13.5V mean your battery is common, if it displays lower than 13V mean your battery is weak. Anyways your weak batteries need to add battery oil to Maintenance by handwork.
The Working Mode:
Constant Voltage:Use the constant voltage to charge batteries,whether the current will start largely,but as it is working will decrease less.
Constant Current:It means the storage battery voltage is lower than the set voltage of this charger, but this charger will supply constant charging current to your batteries so that it can maintenance both the battery and the battery charger.
Trickle Charge Modulation:When the battery voltage is approaching the set voltage and the charging current is lowing to the set current,it will turn to the floating charge mode from trickle charge mode automatically,it means full-charge,but it will keep on floating charge mode.
Floating Charge Modulation:It will keep maintenance-method charging your battery ,but the charging current will be small a bit.
Multi-protection:
Overheating protection:When the temperature of the charger is over 150℃ ,our charger will stop working ,when the temperature reduce to 80℃ or turn off the power ,after 10 minutes,the charger can work again.
Short-circuit protection:When the charger output has short-circuit and automatical stop working will have the long beep alertness. Just connect it exactly, it will be automatically recharging again .
Reverse-connecting protection:When you put the reverse-connection,the charger will automatically close the output and alarm with the long beeps, after exactly to connet it will be automatically recharging again.
