Заводская Прямая поставка сухого жидкого стола машина для сушки

Описание и отзывы

Трекер стоимости

Характеристики

Brief Introduction

Fluid bed drying technology is a new drying technology developed in recent years. The process is that the bulk material is placed on the orifice plate, and the gas is transported from the lower part of it, which causes the particles to move on the gas distribution plate and become suspended in the air flow. Produce a mixture of particles and gases at the bottom, like a liquid boiling. In the fluid bed dryer, the particles are in full contact with the gas in the mixed layer, and the heat transfer and moisture transfer between the material and the gas are carried out. At present, it is widely used in chemical, food, ceramics, medicine, polymer and other industries.

The drying process of fluid bed is that the loose material is placed on the orifice plate, and the gas is transported by the lower part of it, which causes the particle to move on the gas distribution plate, and suspends in the air flow, and produces the mixed bottom layer of the material particle and gas, like a liquid boiling. In the fluid bed dryer, the particles are in full contact with the gas in the mixed layer, and the heat transfer and moisture transfer between the material and the gas are carried out.





Product Description

Working principle:

If the gas passes through a granular bed, the bed will take on a different state with the change of the flow velocity. When the velocity is low, the airflow is only in the gap of the stationary particle, which is called the fixed bed. When the gas velocity increases to a certain value, all the particles are suspended by the upward air flow, and the force of the gas acting on the particles is balanced with the gravity phase of the particles, and the bed reaches the initial fluidization, and the flow velocity is called the minimum fluidization velocity. When the flow velocity exceeds this value and is higher than the terminal velocity of the particle (maximum fluidization velocity), the interface of the bed disappears and the entrainment occurs, and the solid particles flow from the bed with the fluid. Out of this situation is the phenomenon of pneumatic conveying solid particles, or dispersed phase fluid beds.





Features & Applications:

Fluid bed drying has the advantages of high heat and mass transfer rate, high drying rate, high thermal efficiency, compact structure, low cost of basic investment and maintenance, and easy operation. Therefore, fluid bed driers are widely used in chemical, food, ceramic, pharmaceutical, polymer and other industries.





Technical Parameters:

Model	Area of Fluid Bed (M2)	Inlet air Temperature (℃)	Outlet air Temperature (℃)	Motor Power (KW)
ZLG 3*0.3	0.9	70-140	40-70	1.5
ZLG 4.5*0.2	1.35			1.5
ZLG 4.5*0.45	2.05			2.2
ZLG 6*0.6	3.6			3
ZLG 6*0.75	4.5			3
ZLG 6*0.9	5.4			3
ZLG 7.5*0.6	8.5			4.5
ZLG 7.5*0.75	10.65			4.5
ZLG 8*1.8	14.5			11

Tips: Tha above chart of technical parameter is for reference only, the specifically details need to been design and  calculated by engineers under the customers' requirements.





Packing & Delivery

1. Our dryer / drying machine should been cleanned first, then packaged with the transparent coating, next it will been shipped into the marine container with steel wire fixing.

2. Some of the over-size drying machine, we will choose the flat rack container.

3. First the drying machines are transported by land to China's maritime ports, then shipped and delivery, and final the containers are shipped to the customer's designated port of arrival.





Company Information

Our company, Jiangsu Shengman Drying Equipment Engineering Co., Ltd is one of the leading production enterprises in the drying equipment engineering field in China. We have more than 180 employees and hold several workshops, like the independent office building, storehouse, testing laboratory workshop, production workshops and electrical workshop.



At present, we can supply kinds of drying, mixing and grinding equipment, like KJG series hollow blade dryer, PLG series continual plate dryer, XSG series spin flash dryer, ZKG series vacuum paddle dryer, DW series mesh belt dryer, spray dryer, SHK series mixer, 30B grinder, coal-fired hot air furnace and so on.





Honors & Certifications





Our Services Available

Sale service:
1. Ensure product with high quality and pre-commissioning before delivery.
2. Delivery on time.
3. Provide full set of documents as customer’s requirements.



After-sale service:
Provide considerate services to minimize clients’ worries.
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the drying equipment.
3. Train the first-line operators.
4. Examine the drying equipment.
5.Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship with all my clients.



Service commitment:
1. We provide clients one-year warranty to make sure the machine work well.
2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.
3. We send every client a preferential and reasonable quotation.





FAQ

Q: How can i visit your factory?
A: Our company is in Changzhou city, and it is very near Shanghai city. It takes about 1 hour to get to Changzhou. Or we can even visit you in Shanghai.



Q: Are you a factory or a trading company?

A: We are a manufacturer, and have been in the drying industry for more than ten years.



Q: What’s the MOQ of your products?
A: 1 set. For the old customers, we will also provide product accessories.



Q: What’s the quality of your products?
A: Our products come with best quality, and passed CE certification. And exported to lots countries around the world. You can rest assured with the quality absolutely.



Q: What to do if the machine has a problem?
A: 24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.



Q: How long is the warranty of your equipment?
A: One year / 12 months.



Q: What is your payment term?
A: Our usual payment term is T/T. 30% T/T in advance, another 70% T/T before shipment. Other ways can also be received after we discussion and agreement.



Q: Does your price include freight?
A: The price we offer usuallly is FOB Shanghai price. If you request CIF, please give us your delivery port, and even can offer the EXW price (machine cost) for you.





Why choose us ?

1. Quality is sure

2. Price is competitive

3. Service is excellent

4. Delivery on time





Important Notices

In order to quote you the right drying machine machine with best price, we would like to get the following information:

1. Name & state of drying raw material

2. Primary moisture & Final moisture (%)

3. Max drying temperature (℃)

4. Finished products' capacity per hour (KG/H)

5. Heating source (like Natural gas, electricity, fuel oil or steam)

6. Electricity information in the using field (Voltage, Hertz, phase)

7. Steel material of drying machine

8. Other special drying requirements
