400C 26G HZ RS485 Smart Digital Long Distance Radar Level Meter Wireless Level Transmitter For Solid Powder Water And Liquid
A.[Features]------26GHz Radar level transmitter
- Small antenna size, easy to install; Non-contact radar, no wear, no pollution;
- Almost no corrosion, bubble effect; almost not affected by water vapor in the atmosphere, the temperature and pressure changes;
- Serious dust environment on the high level meter work has little effect;
- A shorter wavelength, the reflection of solid surface inclination is better;
- Beam angle is small, the energy is concentrated, can enhance the ability of echo and to avoid interference;
- The measuring range is smaller, for a measurement will yield good results;
- High signal-to-noise ratio, the level fluctuation state can obtain better performance;
- High frequency, measurement of solid and low dielectric constant of the best choice.
B.[Technical Parameters]
The radar level transmitter delived to guide wave and intelligent radar level meter.For different medium and measuring range,We could choose better model for you.
The technical parameters for our hot sale radar level trasnmitter for you reference.CX-RLM-071/072/082/805/808/810...etc..
| TECHNICAL | CX-RLM-071 | CX-RLM-072 | CX-RLM-082 |
| Medium | Liquid, solid powder | Liquid,corrosive liquids | Storing corrosive liquids, slurries and solids |
| Applications | Liquid and solid powder measure, | Acids, bases or other corrosive media | Water tank,Acid and alkali tanks |
| Measuring range | 30m | 20m | 20m |
| Temperature range | -40~250℃ | -40~200℃ | -40~150℃ |
| Accuarcy | ±10mm | ±10mm | +/-3mm |
| Pressure | -0.1~4MPa | -0.1~4MPa | -0.1~2Mpa |
| Output | 4~20mA/HART | 4~20 mA/HART | 4~20 mA/HART |
| Antenna | Single cable or single rod antenna | Full PTFE sealing cable type or rod antenna | PTFE |
| Shell | Aluminum /Plastic | Aluminum /Plastic | Aluminum /Plastic |
| Connection | Flange (optional) / Thread | Flange (optional) / Thread | Flange (optional) / Thread |
| Frequency | 500MHz-1.8GHz | 500MHz-1.8GHz | 6.8GHz |
| Power supply | Two-wire (DC24V) Four-wire(DC24V/AC220V) | Two-wire (DC24V) Fourwire(DC24V/AC220V) | Two-wire (DC24V) Fourwire(DC24V/AC220V) |
| TECHNICAL | CX-RLM-805 | CX-RLM-806 | CX-RLM-810 |
| Medium | All kinds of corrosive liquid | Liquid | Solid material, Strong dust, |
| Measuring range | 10m | 30m/70m | 70 m |
| Temperature range | -40℃ ~ 120℃ | -40℃ ~ 150℃ | -40℃ ~ 250℃ |
| Accuarcy | ± 5mm | ± 3mm | ± 15mm |
| Pressure | -0.1~0.3 MPa | -0.1 ~ 4.0 MPa | :-0.1 ~ 0.1MPa |
| Output | 4... 20mA/HART (Two-wire / Four) RS485/ Modbus | 4... 20mA/HART (Two-wire / Four) RS485/ Modbus | 4... 20mA/HART (Two-wire / Four) RS485/ Modbus |
| Antenna | PTFE | Stainless steel | Stainless steel |
| Protection Grade | IP67 | IP67 | IP67 |
| Explosion-proof Grade | Exia ⅡC T6 Ga | Exia ⅡC T6 Ga | Exia ⅡC T6 Ga |
| Shell | Aluminum /Plastic | Aluminum /Plastic | Aluminum /Plastic |
| Connection | Flange or thread | Flange or thread | Universal Flange |
| Frequency | 26GHz | 26GHz | 26GHz |
| Power supply | wo-wire (DC24V) Four-wire(DC24V/AC220V) | wo-wire (DC24V) Four-wire(DC24V/AC220V) | wo-wire (DC24V) Four-wire(DC24V/AC220V) |
C.[Related Productions]
D.[Company Infor]
| Shanghai Cixi Instrument Co,.Ltd | |
| Name | Sophia |
| Emails | sales1@gninstruments.com |
| Website | www.gninstruments.com |
| Tel/Phone | 86-021-57634819 Phone/Skype/Wechat:+86-13381521778 |
Pls send us an inquiry now,to get factory price.
