Fiberglass mesh glass fiber 80-160gsm fiberglass gridding cloth



We can produce special size Alkali-resistant Fiberglass Mesh according to your requirements:

  • like different mesh size(2.85X2.85mm, 3x3mm, 4x4mm, 4x5mm, 5x5mm, 6x6mm, 8x8mm, 10x10mm)

  • weight per square meter(60g/m2~300g/m2).



2.Specification

A:mesh size: 4×4mm,4×5mm,5×5mm, 5×6mm ,10×10mm,
B. weight per unit area:  75g ----- 200grams Volume
C. width : 1~2M
D. length: 50M -300M

NO.	Specifications	Mesh size mm		Yarn density (tex)		Mass g/m2	Tensile strength N/5X20cm
		warp	weft	warp	weft		warp	weft
1	FG4×4-75	4	4	48/2	200	75±3	700	850
2	FG4×4-90	4	4	67/2	200	90±3	950	1100
3	FG4×4-145	4	4	134/2	240	145±5	1500	1500
4	FG4×4-160	4	4	134/2	300	160±5	1500	1650
5	FG4×5-110	4	5	100/2	360	110±5	1100	1200
6	FG4×5-125	4	5	100/2	280	125±5	1200	1300
7	FG4×5-145	4	5	134/2	300	145±5	1400	1400
8	FG4×5-160	4	5	134/2	360	160±5	1500	1600
9	FG5×5-90	5	5	67/2	240	90±3	950	1150



3.Uses:Reinforcing Wall,Natural Marble,Plaster Board,Artificial Stone,Old building Surface Rebuilding And Reinforcement,Cement, Plastic, Asphalt, Marble, Roof, Wall And So On.





For the fiberglass mesh, it must be:

1.       The alkali-resistant coating is very important, it must be strong, the yarn is not easy to move

2.       The mesh should be clear, regular, there is no big woven mistaken,

3.       We can make soft or stiff mesh according to the customer’s need, but as our experience, the soft mesh is better



Material from JUSHI ; export to Europe, Amercia, Australia market ;do OEM ;clear and nice surface





The quantity of loading for 40'HQ:

1.  120,000m2 per 40'HQ

2.  50,000m2 per 20GP
