Эффективный Улучшенный со шлейфом илоуплотнители цена
- Категория: Загуститель для горнодобычи >>>
- Поставщик: Shandong,Xinhai,Mining,Technology,&,Equipment,Inc.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.44 $* | 0.43 $* |
| Aug-16-2025 | 0.88 $* | 0.82 $* |
| Jul-16-2025 | 0.41 $* | 0.94 $* |
| Jun-16-2025 | 0.34 $* | 0.87 $* |
| May-16-2025 | 0.42 $* | 0.27 $* |
| Apr-16-2025 | 0.25 $* | 0.38 $* |
| Mar-16-2025 | 0.60 $* | 0.3 $* |
| Feb-16-2025 | 0.60 $* | 0.30 $* |
| Jan-16-2025 | 0.21 $* | 0.14 $* |
Характеристики
Product Description
Sludge Thickener---Product Description
[Introduction]: A new efficient thickening equipment independently developed by Xinhai.
[Capacity]: 5-1400t/d
[Improvement]: This thickener is patent product of Xinhai. After improvement, the capacity becomes larger, overflow with low turbidity and discharge with high concentration
[Capacity]: 5-1400t/d
[Improvement]: This thickener is patent product of Xinhai. After improvement, the capacity becomes larger, overflow with low turbidity and discharge with high concentration
Product Advantages
Sludge Thickener---Product Advantages
01 Out overflow weir instead of inner overflow weir increases the sedimentation area and not easy to block;
02 Oblique feeding instead of horizontal feeding solves the blockage problem;
03 A tranquil flow device reduces material flow rate, so that the overflow becomes more uniform with lower turbidity.
02 Oblique feeding instead of horizontal feeding solves the blockage problem;
03 A tranquil flow device reduces material flow rate, so that the overflow becomes more uniform with lower turbidity.
Product Structure
Sludge Thickener---Product Structure
The vertical axis rotates driven by motor, and pulp by feeding device flows into the tank center feed mixing barrel.Solid material in the bottom of the tank by the scraper moves out of center; clarified overflow through the tranquil flow device flows out from the ring external overflow weir.
Technical Parameters
Model | Tank Diameter (mm) | Tank Depth (mm) | Subsidence Area (m2) | Capacity(t/d) | Motor Model | Motor Power(kW) | Steel Tank Weight (kg) | Weight(kg) |
NZSG-2.5 | 2500 | 1850 | 4.9 | 5 ~22.4 | Y90L-6 | 1.1 | 1000 | 2225 |
NZSG-3A | 3000 | 1800 | 7 | 5 ~23.3 | Y100L-6 | 1.5 | 1664 | 3168 |
NZSG-3 | 3600 | 1800 | 10.2 | 5 ~28.5 | Y100L-6 | 1.5 | 2097 | 3680 |
NZSG-5 | 5000 | 2956 | 16 | 16 ~90 | Y90L-4 | 1.5 | 5160 | 8031 |
NZSG-6 | 6000 | 2956 | 28.3 | 98 | Y90L-4 | 1.5 | 5769 | 9200 |
NZSG-7 | 7000 | 3000 | 38.5 | 140 | Y112M-6 | 2.2 | 8800 | 13862 |
NZSG-8 | 8000 | 3318 | 50.2 | 185 | Y132S-6 | 3 | 12966 | 19158 |
NZSG-9 | 9000 | 3376 | 63 | 210 | Y132S-6 | 3 | 15418 | 21733 |
NZSG-12 | 12000 | 3600 | 113 | 370 | Y132S-6 | 3 | 25589 | 34823 |
NZSG-15 | 15000 | 3600 | 176 | 580 | Y132S-4 | 5.5 | 35800 | 54315 |
