 High Pressure Hydraulic Oil Micro Oval Gear Flow Meterseter

A.[Feature of Micro oval gear flow meter]



High Accuracy

The standard type is 0.5%,for some special medium the accurcy is 0.2%.



The Min Flow Range

The min flow range is 0.5ml/min,The M2 flow range is 0.5~150ml/min.



The Max Pressure and Temperature

The standard type is 32Bar and 80℃,But can customized  for 1000Bar and 150℃.



Dosing and Alarm Function

The micro oval gear flow meter wiht display instrument could reach the dosing and upper and Lower Alarm.



The Quality Material of micro flowmeter

The Micro oval gear flow meter with stainless steel 316lL and Aluminum material to suitable for the medium.



Speical and Strict working condition

The micro oval gear flow meter suitable for Hydraulic system;Painting;Test Bench and more.



B.[Parameter]



Model	Flow Range	Connection
CX-M2-SS/AL	0.5~150 ml/min	NPT/G 1/8''Female thread
CX-M3-SS/AL	3~300 ml/min	NPT/G 1/8'' Female thread
CX-M5-SS/AL	5~1000 ml/min	NPT/G 1/8''  Female thread
CX-M6-SS/AL	0.5~100 L/H	NPT/G 1/4' Female thread
CX-M9-SS/AL	6~600 L/H	NPT/G 1/4'' Female thread
CX-M12-SS/AL	0.3~30 L/Min	NPT/G 1/2'' Female thread
CX-M25-SS/AL	0.5~100 L/Min	NPT/G 1'' Female thread
Test Bench flowmeter	1~800 ml/min	NPT/G 1/8' Female thread



Accuracy	The standard type is 0.5%,some special medium is 0.2%
Temperature	-40~80℃(the max temperature is 150℃)
Pressure	32Bar (the max pressure 1000Bar)
Output	The putput is pulse output
Power Supply	4~26VDC
-SS series
Material	Chamber:SS316 ; Gear;SS316L ;Shaft:SS316L
Medium	Suitable for various chemical liquid
-AL Series
Material	Chamber:Aluminium ; Gear:Aliuminium ;Shaft:SS316L
Medium	Suitable for Non-various chemical liquid

Model / Size	M2  M3  M5	M2  M3  M5(High Pre)	M6	M9	M12	M25
A	30	30	40	47	44	56
B	62	62	72	79	79	91
C	G1/8''	G1/8''	G1/4''	G1/4''	G1/2''	G1''
D	40	40	50	60	85	100
E	M5*31	M5*31	M5*42	M5*72	M5*72	M6*61



C.[ Working Condition ]

    a.Hydraulic System,Hydraulic oil

• The strict working condition,So the micro flow meter must with longer workinglife;


• The Hydraulic system with high pressure,Normal the pressure is more than 16Mpa;


• Test for Hydraulic oil,The medium must is pure,the micro flow mete need provide the filter;


• The Hydraulic system is more professional system,So the manufacture with professional engineers and Low cost aftersales.

   b. The common rail injector test bench

• The test bench micro flow meter's flow range is 0.7~400 ml/min,Our micro flowmeter is 1~800 ml/min;


• The special flow meter need higher pulse parameter,The Model M3 with 0.07 ml/pulse;


• In the test process,The Micro flow meter need provide the filter.

  C. The Painting industry and painting mechine

• The micro flow meter need higher accuracy;


• The flowmeter need control the flow range and stable output;


• Artifical painting waste much time and it is easy cause much cost loss;

  D.The Dispensing industry

•  The flow meter of dispensing industry should be with higher accuracy.


• The flow meter should be with dosing function.


• The medium of dispensing with high viscosity and variety meduim.


• The micro flow meter should be with lower flow range.
