Высококачественный цифровой кориолисовый газовый расходомер Ss316l от профессионального производителя для жидкостей
- Категория: Денситометры >>>
- Поставщик: Beijing,Sincerity,Automatic,Equipment,Co.,Ltd.,Tongzhou,Branch
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 2856.31 $* | 2999.89 $* |
| Aug-16-2025 | 2832.64 $* | 2974.79 $* |
| Jul-16-2025 | 2376.27 $* | 2495.6 $* |
| Jun-16-2025 | 2784.70 $* | 2923.82 $* |
| May-16-2025 | 2424.45 $* | 2545.35 $* |
| Apr-16-2025 | 2736.87 $* | 2873.9 $* |
| Mar-16-2025 | 2712.12 $* | 2848.77 $* |
| Feb-16-2025 | 2688.10 $* | 2822.97 $* |
| Jan-16-2025 | 2664.68 $* | 2797.97 $* |
Характеристики
Product description
| Code | Product | |||||||||||
| CR | DMF-1-CR Insertion Density Meter | |||||||||||
| code | Fork Material | |||||||||||
| A | SS 316L | |||||||||||
| B | HC Hastelloy | |||||||||||
| C | SS316L with PTFE | |||||||||||
| D | HC Hastelloy with PTFE | |||||||||||
| code | Output | |||||||||||
| E | 4-20mA 0-1000Hz RS485 Modbus RTU | |||||||||||
| code | Power Supply | |||||||||||
| A | 24VDC | |||||||||||
| B | 220VAC | |||||||||||
| code | Transmitter Casing Material | |||||||||||
| F | Aluminium Alloy | |||||||||||
| code | Pressure Class | |||||||||||
| 16 | 1.6MPa | |||||||||||
| 40 | 4MPa | |||||||||||
| XXX | Special pressure can be ordered | |||||||||||
| code | Process Connection | |||||||||||
| A | DN50 HG/T 20592-2009 RF | |||||||||||
| B | Chuck Connection | |||||||||||
| XXX | Special connection can be ordered | |||||||||||
| code | Length | |||||||||||
| 128 | Standard 128mm | |||||||||||
| XXX | Special length can be ordered | |||||||||||
| code | Extension Pipeline Material | |||||||||||
| A | Without extension pipeline | |||||||||||
| B | SS 316L | |||||||||||
| C | HC Hastelloy | |||||||||||
| D | SS 316L with PTFE | |||||||||||
| E | HC Hastelloy with PTFE | |||||||||||
| code | Flange Material | |||||||||||
| A | SS 316L | |||||||||||
| B | HC Hastelloy | |||||||||||
| C | SS 316L with PTFE | |||||||||||
| D | HC Hastelloy with PTFE | |||||||||||
| code | Installation Method | |||||||||||
| A(XX) | Horizontal Pipeline (XX:Pipeline Size) | |||||||||||
| B(XX) | Vertical Pipeline (XX:Pipeline Size) | |||||||||||
| C | Tank Installation | |||||||||||
| D | Other installation method can be special ordered | |||||||||||
| code | Factory Setting | |||||||||||
| G | Factory Setting Options | |||||||||||
| CR | A | E | A | F | 40 | A | 128 | A | A | A | G | Ordering Information |
Product installation
Vibration turning fork :
The density meters can be installed on both pipelines and in the tanks. If the pipeline size is less than DN150, (6” ) then the enlargement of the pipeline size is required.
Product Process
Related Products
Company introduction
[ THEY TRUST US ]
We had the honor to serve some famous companies all over the world such as, Coca-cola, redbull, unilever, volkswagen, Samsung, Sinopec, Petro China, CNOOC etc.
Certification
Kindly Reminder :
all our certifications are REAL ONE.
NOT FAKE , NOT FAKE , NOT FAKE !!!
PLEASE CONTACT US TO SHOW YOU!!!
