Стальная проволока резиновый шланг высокого давления DIN 4SH 4SP гидравлический


Поделиться:


Цена:175,98 ₽*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Aug-16-2025 222.9 $* 226.42 $*
Jul-16-2025 180.95 $* 184.25 $*
Jun-16-2025 219.98 $* 223.6 $*
May-16-2025 217.28 $* 221.46 $*
Apr-16-2025 173.85 $* 176.4 $*
Mar-16-2025 214.28 $* 218.98 $*
Feb-16-2025 212.36 $* 216.3 $*
Jan-16-2025 210.10 $* 214.52 $*

Характеристики

hydraulics

 Black High Quality Hydraulic Rubber Hose

Complete Range of  Size from 3/16" to 4"
Various Color: Black, Red, Blue, Yellow, Gray
Different Surface: Smooth or Wrapped
Different Marking: Printing or Engraved

Tube: Oil resistant synthetic rubber
Cover: Abrasion and weather resistant synthetic rubber
Temperature range: -40 degree centigrade To +100 degree centigrade


This Steel Wire Hose is mainly intended for diverse applications in the fields of forestry, agriculture, construction and others. It is integrated with a bend radius capability which allows an intuitive mounting and routing. This also enables a longer hose life in various curving applications and some of the bent tube fitting needs.

It is enclosed with a black and oil resistant cover which is also integrated with a synthetic rubber. Its cover also comes with a color-optional line of marking. Its tube is black in color and is built with an oil-resistant tube material which enables high pressure and high temperature functionality.
Steel Wire High Pressure Rubber DIN 4SH 4SP Hydraulic Hose Factory Wholesale
Size (Inch) Inside Diameter Reinforcement Outside Diameter Proof Pressure Working Pressure Burst Pressure Bend Radius
Nom (mm) Min (mm) Max (mm) Min (mm) Max (mm) Nom (mm) Min (mm) Max (mm) (Bar) (Psi) (Bar) (Psi) (Bar) (Psi) (mm)
3/16" 4.8 4.6 5.4 9 10 11.5 11.1 13 500 7300 250 3650 1000 14600 85
1/4" 6.4 6.2 7 10.6 11.6 13 12.7 14 450 6500 225 3250 900 13000 100
5/16" 7.9 7.7 8.5 12.1 13.3 14.7 14.3 16 430 6200 215 3100 860 12400 115
3/8" 9.5 9.3 10.1 14.5 15.7 17 16.7 18 360 5200 180 2600 720 10400 130
1/2" 12.7 12.3 13.5 17.5 19.1 20.1 19.8 21 320 4600 160 2300 640 9200 180
5/8" 15.9 15.5 16.7 20.6 22.2 23.2 22.9 25 260 3800 130 1900 520 7600 200
3/4" 19 18.6 19.8 24.6 26.2 27.2 26.9 29 210 3000 105 1500 420 6000 240
1" 25.4 25 26.4 32.5 34.1 35.1 34.6 37 176 2600 88 1300 352 5200 300
1-1/4" 31.8 31.4 33 39.3 41.7 42.8 42.2 45 126 1800 63 900 252 3600 420
1-1/2" 38.1 37.7 39.3 45.6 48 49.6 49.1 52 100 1500 50 750 200 3000 500
2" 50.8 50.4 52 58.7 61.7 62.5 62.5 66 80 1200 40 600 160 2400 630
hydraulic hose 04hydraulic hose 01hydraulic hose 05hydraulic hose 02hydraulic hose SAE R1hydraulic hose SAE R2hydraulic hose 02hydraulic hose 03

Smooth Cover hydraulic hose.jpg
blog-mangueriaindustrial-hoses

.jpg

.jpg


FAQ ( Frequently Asked Question)

1. Is sample available? Shall I pay for sample or delivery?

Free samples and free delivery.

2. How long will I get my order?

General production time for 1x20 feet container is 10-15 days, for 1x40 feet container 20-25 days.

3. How will my order be packed?

All hose is packed by 2 plies of PVC film, inner is tranparent, outer is color and thick one. (Color can be ordered as customer like). Special packing like Reel and Pallet also available. Fitting is packed by 3 plies, carton, PVC bag and then pallet.

4. What should I do if I find quality problem in using?

12 months Quality Garentee for all of our products. We offer replacement for any defective caused by non-human reasons.

5. Is it possible to visit your factory?

We warmly welcome you to visit our factory at any of your convenient time.
