Стерилизатор Uht для жидких продуктов высококачественный

Product Application

The plate sterilizer machine is sterilization equipment specially designed for juice,tea drinks or similar liquid materials. It is the ideal equipment that material can extend the shelf life purpose through sterilizing and cooling. According to users’ different requirements to material heating, sterilization, heat preservation and cooling, to design various technical requirements for different flow assembly, meet the technological requirements and have all kinds of security protection measures and high temperature alarm, low temperature function of the back flow. At the same time, according to users’ requirements, corresponding configuration of high accuracy of the automatic control system.
Semi-automatic configuration: the whole process of operation is semi-automatically control. Operator can control the pumps, valves and back flow function on the control panel. By the temperature control PID to maintain the sterilization temperature. Sterilization temperature has a continuous record.

Technical process:
For milk:
5°C milk→65°C-75°C Homogenize→85°C-90°C Pasteurize(15s)→4°C Packing
For Juice:
Juice 30°C→ (65-75)°C Homogenize→(137)°C Sterilize(4s)→88°C filling and packaging→30-45°C Circumfluence
Characteristics:
1. Heat transferring efficiently
2. Energy saving
3. Temperature controlling is more accuracy
4. No touching the liquid, more hygiene
5. Cleaning more easily

Main Features

This product consists of three parts, heating, sterilizing and cooling, and plate and tube sterilization can be combined in many ways with two separate heating and cooling sections for in-line homogenization. The temperature of the product can reach 140 degrees centigrade. All parts of the equipment in contact with the products are made of SUS 316 stainless steel. The sleeves, washers and seals are made of food grade fluorine rubber. DIN pipe fittings are used to connect the product pipes. In the display output, the UHT type sterilization machine configurable touch screen PLC semi automatic program control and manual control system, and can according to user requirements selection pressure gauge or digital sensor, the temperature of the product flow and other parameters to reflect the dynamic. Therefore, the equipment can simulate the vast majority of industrial production in the laboratory.

FAQ

Q1: Are you a trading company or a manufactory?
A1: We are the manufacture of water/beverage packing machine and water treatment equipment over 5years.We just not only sell machines, we sell our brand and service.
Q2: Do you have technical support after we purchased your machines?
A2: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems.
Q3: If you buy our machines, can you offer us wear-out spare pats?
A3: We provide our high quality machine 1 years guarantee , and we will also offer you 1 years wear-out spare parts for free. Once your machines broken or doesn't work within 1 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.
