30ftx100ft Light Deprivation Blackout Greenhouse With Cooling System
Product Description
Blackout PO Film Single Span Greenhouse:
The blackout PO film single-span greenhouse is a type of simple, safe and convenient universal greenhouse; it uses hot-dip galvanized steel pipes as the main framework, spare parts made under the hot-dip galvanized pressuring technique. The single-span greenhouse is mainly for vegetable and fruit cultivation and other usage, besides its excellent insulation properties and necessary ventilation performance. We can also add sides manual rolling ventilation system to make it more practical. It works together with light deprivation system to realize the 100% shading rate.
Blackout PO Film Single Span Greenhouse Frame:
PO film, heat-preserving and durable, can be available on the roof and side of the greenhouse, thickness of which can be 8mm,10mm, 12mm, 15mm, 20mm, etc. And more layers of the film can be used on the greenhouse.
Parameters
Single Span Greenhouse | ||
Main Frame | Hot Galvanized Steel Pipe | |
Covering Material | PO Film | |
Covering Material Lifetime | 3-5 years | |
Column Shape | Rectangular | |
Span | 8m/9m/10m/12m | |
Width Between Columns | 4-8m | |
Layer | 1 layer/2layer | |
Top Height | 3m-7m | |
Gutter Height | 2.5m-6.5m | |
Wind Load | 0.5KN/m² | |
Snow Load | 0.3KN/m² | |
Pictures Show
Optional Systems
Optional System | ||||
NO. | Name | Remarks | ||
1 | Cooling system | Cooling pad and fan | ||
2 | Shading system | Inside and outside shading | ||
3 | Ventilation system | Film-rolling ventilation | ||
4 | Heating system | Heating pad | ||
5 | Grow Light | LED lights/high pressure nano lamp | ||
6 | Irrigation system | Drip irrigation, mist system | ||
7 | Seedbed | Movable, fixed | ||
8 | Circulation system | Circulating fan | ||
9 | Planting System | Control all Felt Planting Bag | ||
Light deprivation greenhouse-
* Shading system
100% shading rate black film, controlled opening and closing by curtain pulling system.
Light deprivation greenhouse-
*Ventilation system
Film Rolling Ventilation, Film rolling machine can choose electric film rolling machine or manual film rolling machine.It is easy to install and operate.
Light deprivation greenhouse-
Cooling fan
Cooling fan Size (mm) :
1, 1530mm * 1530mm * 400mm.
2, 1380mm * 1380mm * 400mm.
2, 1380mm * 1380mm * 400mm.
Light deprivation greenhouse-
Cooling pad
Cooling pad size (mm) :
1, Thickness 200mm, height 1500mm.
2,Thickness 150mm, height 1500mm.
3,Thickness 100mm, height 1500mm.
2,Thickness 150mm, height 1500mm.
3,Thickness 100mm, height 1500mm.
Light deprivation greenhouse-Circulating fan
Light deprivation greenhouse-High pressure micro-fog machine
Light deprivation greenhouse-Dehumidifier
Light deprivation greenhouse-Seedling tray with lid
Light deprivation greenhouse- Seedling shelf movable
1, With wheel seedling shelf, easy to move.
2, The number of layers can be customized, 1500m length, 565mm width.
2, The number of layers can be customized, 1500m length, 565mm width.
3, Can be replaced with shelves, cost savings.
Light deprivation greenhouse-Black and white film bag
1,Size:10 cm x 12 cm.
2, It is used in the seedling stage of hemp, and the bottom air vent is designed for water leakage and ventilation.
Advantage:
(1) The height is suitable and easy for workers to work
(2) Accelerate air flow and optimize growth environment.
(3) Easier control of crop diseases and crop growth.
(4) Root temperature is more favorable than ground growth.
(5) Improve work efficiency.
The frame height is 10cm, width and length can be customized.
(1) The height is suitable and easy for workers to work
(2) Accelerate air flow and optimize growth environment.
(3) Easier control of crop diseases and crop growth.
(4) Root temperature is more favorable than ground growth.
(5) Improve work efficiency.
The frame height is 10cm, width and length can be customized.
Light deprivation greenhouse- Tidal seedbed
Advantage:
(1) More uniform irrigation.
(2) Beneficial to the treatment of diseases
(3) Save water and fertilizer.
(4) Promote plant growth.
(5) Cleaner production environment
(6) Improve the efficiency of labor production. The seedbed is composed of leg frame, tide plate, aluminum alloy frame, roller and
other parts.
The frame height is 10cm, width and length can be customized.
The usual sizes of tidal plates are 3ftx6ft, 4ftx8ft and 5ftx10ft.
(1) More uniform irrigation.
(2) Beneficial to the treatment of diseases
(3) Save water and fertilizer.
(4) Promote plant growth.
(5) Cleaner production environment
(6) Improve the efficiency of labor production. The seedbed is composed of leg frame, tide plate, aluminum alloy frame, roller and
other parts.
The frame height is 10cm, width and length can be customized.
The usual sizes of tidal plates are 3ftx6ft, 4ftx8ft and 5ftx10ft.
Light deprivation greenhouse- Felt planting bag
1, Using felt buckets to grow with a growing matrix, to avoid possible pest damage in the soil and to provide a healthier
environment for crop to grow.
environment for crop to grow.
2, Specifications: 1 gallon, 3 gallons, 5 gallons, 7 gallons, 10 gallons, 15 gallons.
Light deprivation greenhouse-
Grow light * LED lights
1, 18W/piece, 8 pieces in a group.
2,When the greenhouse or planting workshop does not have enough light, it can supplement the light for the growth of crop and accelerate the growth.
Light deprivation greenhouse-
Grow light * High pressure nano lamp
1, One for every 30 square meters.
2,When the greenhouse or planting workshop does not have enough light, it can supplement the light for the growth of crop and accelerate the growth.
Light deprivation greenhouse- Water&fertilizer machine
1. Intelligent irrigation water and fertilizer integrated machine, stainless steel fertilizer pump, 4 channels for fertilizer injection, each channel works independently, flow 30-1500ml /Min control accuracy 1Ml.
2. EC, PH online monitoring, online control EC value, PH value.Automatic adjustment of fertilizer shunt ratio.
3. 7-inch color touch screen.Automatic irrigation and fertilization can be realized through Internet of things control to save
time and labor.
2. EC, PH online monitoring, online control EC value, PH value.Automatic adjustment of fertilizer shunt ratio.
3. 7-inch color touch screen.Automatic irrigation and fertilization can be realized through Internet of things control to save
time and labor.
