NVR4104HS-P-4KS2 4K H.265 сетевой видеорегистратор 4-канальный 4poe Поддержка одного жесткого диска порт

NVR4104HS-P-4KS2 4K H.265 сетевой видеорегистратор 4-канальный 4poe Поддержка одного жесткого диска порт

Категория: Surveillance Products >>>
Поставщик: Shenzhen,Lin,Wei,Ke,Xun,Technology,Co.,Ltd.

Цена:85,00 $ - 100,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-15-2025	108.24 $*	110.32 $*
Jul-15-2025	88.99 $*	90.68 $*
Jun-15-2025	106.10 $*	108.92 $*
May-15-2025	105.8 $*	107.25 $*
Apr-15-2025	84.57 $*	86.44 $*
Mar-15-2025	104.7 $*	106.82 $*
Feb-15-2025	103.89 $*	105.62 $*
Jan-15-2025	102.56 $*	104.80 $*

Характеристики

Key features

4 Channel POE NVR NVR4104HS-P-4KS2 NVR4104HS-P-4KS2/L

4 Channel Compact 1U 4PoE Lite 4K H.265 Network Video Recorder
H.265/H.264 codec decoding
Max 80Mbps incoming bandwidth
Up to 8Mp resolution preview&playback
Up to 1ch@8MP/4ch@1080P decoding
HDMI/VGA simultaneous video output
Support IPC UPnP, 4PoE ports

Product Description

Style	4 Channel POE NVR NVR4104HS-P-4KS2
System
Main Processor	Dual-core embedded processor
Operating System	Embedded LINUX
Audio and Video
IP Camera Input	4 Channel
Two-way Talk	1 Channel Input, 1 Channel Output, RCA
Display
Interface	1 HDMI, 1 VGA
Resolution	HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720
	VGA: 1920×1080, 1280×1024, 1280×720
Decoding Capacity	1ch@8MP 30fps, 4ch@1080P 30fps
Multi-screen Display	1/4
OSD	Camera title, Time, Camera lock, Motion detection, Recording
Recording
Compression	H.265/H.264
Resolution	8MP/6MP/5MP/4MP/3MP/1080P/720P/D1&etc.
Record Rate	80Mbps
Bit Rate	16Kbps ~ 20Mbps Per Channel
Record Mode	Manual, Schedule(Regular(Continuous), MD, Stop
Record Interval	1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events	Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
Video Detection	Motion Detection, MD Zones: 396 (22 × 18),
	and Tampering
Alarm input	N/A
Relay Output	N/A
Playback and Backup
Sync Playback	1/4
Search Mode	Time /Date, MD and Exact Search
	(accurate to second)
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
Backup Mode	USB Device/Network
Third-party Support
Third-party Support	Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Network
Interface	1 RJ-45 port (10/100Mbps)
PoE	4 ports (IEEE802.3at/af)
Network Function	HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support DH IP camera, DVR, NVS and etc.), Easy4ip
Optical Fiber Interface	N/A
Max. User Access	128 users
Smart Phone	iPhone, iPad, Android
Interoperability	Open Network Video Interface, SDK, CGI
Storage
Internal HDD	1 SATA III Port, up to 6TB capacity for each HDD
HDD Mode	Single
eSATA	N/A
Auxiliary Interface
USB	2 ports (1 Rear USB2.0, 1 Front USB2.0)
RS232	N/A
RS485	N/A
Electrical
Power Supply	Single, DC48V/1.25A
Power Consumption	NVR: <5.3W (without HDD)
	PoE: Max 25.5w for single port, 50w in total
Environmental
Operating Conditions	-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions	-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions(W×D×H)	Compact 1U, 260mm×224.9mm×47.6mm
	(10.2 x 8.9 x 1.9")
Net Weight	0.8kg (1.76 lb) (without HDD)
Gross Weight	1.6kg(3.53 lb)(without HDD)

Notice

Dear customers, choose us and you will definitely feel the value.If the same product we compete with Quality, if the same quality we compete with Price, if the same price we compete with Service, if the same service we compete with Consistency

We sell Dh and HIK vision all the network products. Please contact us freely.

What is IP camera how it works?

An Internet Protocol camera, or IP camera, is a type of digital video camera that receives control data and sends image data via
the Internet. They are commonly used for surveillance. Unlike analog closed-circuit television (CCTV) cameras, they require no
local recording device, but only a local area network

It is can multi-platform monitor anywhere,any country and anytime .

What is camera PoE?

Power over Ethernet (POE) is a technology that lets network cables carry electrical power. For example, a digital security camera
normally requires two connections to be made when it is installed: A network connection, in order to be able to communicate with
video recording and display equipment.

How to Choose the camera resolution

How to choose the camera lens

How the CCTV system work

Q. What's the actual products I can get?
A: Usually OEM made by Hik/DH(no logo on the products). Customs order is welcome here. Pls contact with the sales for more details for you need.

Q. What's ETA time and stock status?
A: With Sales & Support department and US/EU/AU warehouse, we provide most lines of stock products. So if stock products, the ETA is about 3-5 days, and for products with bulk quantity, the delivery time is about 2-4 weeks.

Q. Do you provide warranty for your products?
A: Yes, we promise 2 years warranty for all our products, OEM products are with 3 years.

Q.What is your method of payment?
A: T/T, Western Union, Paypal, credit card is welcomed.

Q.What is Minimum Order Quantity?
A: Sample order is welcomed, while the price is more competitive for big quantity .

Q: How to ship the goods?
A: For small parcels, we recommend to use the express, such as Fedex, DHL, Fedex, TNT, UPS etc. For bulk order, we can ship the products to your forwarder or will find a best shipping way for you.
