Осевой установленный 0-100Mpa 4 цифры светодиодный металлический корпус цифровой датчик

Осевой установленный 0-100Mpa 4 цифры светодиодный металлический корпус цифровой датчик

Категория: Pressure Switches >>>
Поставщик: Shanghai,Benxu,Electronics,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.95 $*	0.96 $*
Aug-17-2025	0.45 $*	0.90 $*
Jul-17-2025	0.83 $*	0.59 $*
Jun-17-2025	0.12 $*	0.30 $*
May-17-2025	0.99 $*	0.41 $*
Apr-17-2025	0.42 $*	0.62 $*
Mar-17-2025	0.83 $*	0.90 $*
Feb-17-2025	0.17 $*	0.14 $*
Jan-17-2025	0.21 $*	0.62 $*

Характеристики

Our Advantages

Why choose BENXU?

♦ Focus on Sensor Production all the time

♦ The Best Quality with Reasonable Factory Directly Price

♦ Have Passed CE,RoHS etc Certificates

♦ 18 Months Quality Guarantee Starting from the Date of Delivery

Do you care about followings after place an order?

♦ Quality problem?

BENXU signs the 18 months warranty of quality with you.

♦ Price problem?

If think price is higher at same top quality by comparison with others,we will refund you.

♦ After sale problem?

Artificial damage:will offer technical support.

Quality problem:will do repair or offer replacement without any cost within 18 months.

♦ Can’t deliver in time or some other problems?

Go ahead with Trade Assurance Online:

Product Description

Applications:

Water treatment system and air compressor;

Medical treatment and agriculture machine;

Mechanical and electronic automation;

Pneumatic and hydraulic system;

Engineering equipment and test equipment.

Characters:

1,Setting upper and lower limit value and alarm point by your requirements;
2,Relay signal output to avoid the device operate invalidly frequently;
3,Have longer life time by comparison with traditional mechanism switch;
4,Nice controlling accuracy,anti-vibration,strong anti-jamming ability and fast response;

5,Easy to connect the wires and install;

6,Control the pressure in time with 4 digit LED display;

7,It can keep all setting when the power cut off;

8,Will work for pressure cycle 100000 times.

Technical Parameters:

Pressure Range	0-100Mpa(Optional)
Accuracy	0.5%FS
Power Supply	12VDC;24VDC;220VAC;380VAC(Optional)
Alarm Point Setting	Can set any point in the full scale
Output Signal	1 Relay output or 2 relay output(upper limit disconnect,lower limit contact)
Overload Capacity	150%FS
Long-term Stability	0.5%FS/year
Pressure Unit	Mpa;kgf/cm²;PSI
Overload Capacity	380V 3A; 220V 5A; 24V 5A
Using Temperature	-20℃ to 80℃
Compensation Temperature	-10℃ to 60℃
Electrical Protection	Short-circuit protection;reverse protection;anti-electromagnetic interference
Sampling Frequency	5 times/second
Measurement Medium	Which is compatible with stainless steel
Installation Connection	G1/2;G1/4;NPT1/4;NPT1/8 etc;Stainless steel
Connection Wires	Power(red and blue);Output(black and white) for DPS31P/DPS31N Power(red/black);NO(white/yellow);NC(brown/grey);common terminal(green/blue) for DPS31D
Case Material	304 Stainless Steel
Sensor Chip	Ceramic pressure sensor Core
