Графитовый комплект пресс-форм

Цена:33,00 $ - 38,00 $*

Количество:

Product Parameters

Good Mechanical Performance	There is no residual stress, permanent strong joints, good tensile strength and other mechanical properties.
Strong current Load Capacity	Solder joints and metal conductors are molecular binding. The solder joint current carrying capacity equal to conductor . DC resistivity change close to zero after the welding point.
Resistant To Large Repeated Current	The joint's melting point is equivalent to the conductor, can withstand repetitive high current (fault) the impact, the joint no fuse phenomenon.
Convenient And Safe Construction	No need outside energy, professional equipment and professional welding operator, can be operated safely indoors and outside, short welding time .
Controllable welding Temperature	The product can achieve different reaction temperatures (up to 3400 ℃) by adjusting the ratio of the flux

Material	Graphite
System Content	Graphite Mold, Flint Gun, Heat Resistant Glove, Fastening Clamp, Metal Disc, Powder, Steel Brush, Banister Brush, etc.
Characters	Cost-effective, no extra power required makes it portable
Life	About 80 times
Operation	Easy and nospecial skill needed

Operation Instruction

l Check to ensure the graphite mold and conductor is clean ,no residue before making the connection

l Use a propane torch to dry wire conductors and remove remaining cleaning residue, solvent, or water before making the connection.

l Close the graphite mold lid before ignition ,and close the lid tightly

l Insert the conductors and position them for the connection.Ensure them in the center of cavity.

l Keep the irrelevant personnel 1.5M away when welding

l Keep the inflammable goods 1-2M away when welding

l The operator must be equipped thermal barrier glove

l Don’t face to the mould opening when welding

l The operator keep 1.5M away mould is must after ignition

l Don’t touch the mould and connected parts directly after welding

l Open the mould and take the joint out with wrench 10-20S later after reaction .

l Insulate the joint after the conductor cooling completely .

exothermic welding.jpg


Why Chooes Us

Transaction Flow

FAQ

Question	Answer
1. Are you factory or trader?	We are professional manufacturing factory
2. How to order?	Normally the customer can order our products by Alibaba platform or contact our representative by Email. After receving your message, our sales will confirm with you about the specification or other required details then we will send an official invoice to you via mail, which will be included the details of your order and bank information stamp and signed by manager.
3. Do you accept OEM manufacture?	Yes.
4. What's your lead time?	Generally,the lead time is about 20 days after getting your down payment,the real time depends on your order condition.
5. what's your payment Term?	Generally, 30% down payment and the remained should be effected before shipping.
6.Where is your nearest port?	Ningbo or shanghai, both of them are about 3 hours ride.
