Insulation Material

Perlite

It is a rigid, high temperature, water resistant molded perlite thermal insulation available in block, pipe or molded fitting form. The product is a light grey material with dark heat stabilized flecks throughout the product for easy identification. At temperatures up to 600° F, Perlite is extremely resistant to water absorption. Mechanical strength and thermal performance are preserving and the insulation will not act as a reservoir for jacket corrosion as is common with many other rigid insulations.

Specification Compliance

• ASTM C 610, ASTM C 795, MIL-I-24244C (SH), NRC Reg. Guide 1.36

---

Calcium Silicate
Calcium Silicate Pipe and Block Insulation is a molded, high temperature, abuse-resistant pipe and block insulation with exceptional structural strength, composed of hydrous calcium silicate for use on systems operating up to 1200°F (649°C).

Calcium silicate pipe & block insulation meets or exceeds the physical property requirements of ASTM C 533, Type I.

Calcium Silicate has superior resistance to breakage and physical abuse.

Because of its strength, low thermal conductivity and durability, calcium silicate pipe and block insulation is the preferred product for application on high temperature piping and equipment. Recommended for use in the petrochemical and power generation industries.

---

Rockwool

Rockwool is precisely engineered Resin Bonded Fibrous Insulation to offer maximum resistance to heat passage. Our Rockwool fibres are spun from selected rocks, melted at 1600 ° Celsius and blended to a carefully adjusted chemical composition. Their centrifugally spun fibres have a diameter 1/20th that of human hair. These are felted using State of the Art Technology into bonded and cured pipe sections, slabs, Mattresses to optimum density and resilience.

---

Polyurathene

Polyurethane (PUR) CFC Free rigid closed cell foam is one of the most efficient, high performance insulation material, enabling very effective energy savings with minimal occupation of space. PU CFC Free rigid closed cell foam in a wide range of densities for different applications. Density 35 to 65Kg/m3 for Pipe, Slab, Equipment, Vessel and Tank Insulation.



---

Poly Isocyanurate (PIR)

Polyisocyanurate CFC free rigid closed cell foam manufactured in similar way to standard Polyurethane, Polyisocyanurate has all the characteristics and advantages of rigid Polyurethane foam but offers greatly increased resistance to burning and spread of flame and is able to withstand temperatures up to 140oC. When subjected to fire the outer surface of the foam forms a strong carbonaceous layer, which retards further flame spread and penetration.

---

Phenolic Foam

It is Cost effective because lower thermal conductivity facilitates usage of lesser thickness of Phenolic Foam for the same level of insulation. A Wide service temperature range between -196 0C to +130 0C makes Phenolic Foam ideal for low temperature and cryogenic applications. It can be ¬effectively used on LSHS, fuel oil and low pressure steam and hot water lines. Lower K Value (K Value = 0.023W/mk) – that means exceptionally low thermal conductivity.

---

ARMAflex

AP Armaflex® Pipe Insulation is a closed cell, fiber-free elastomeric thermal insulation.  It is manufactured without the use of CFC’s, HFC’s or HCFC’s. All AP Armaflex® products are made with Microban® antimicrobial product protection for added defense against mold on the insulation.

AP Armaflex® Pipe Insulation is used to retard heat gain and control condensation drip from chilled water and refrigeration systems. It also efficiently reduces heat flow for hot-water plumbing and liquid-heating and dual temperature piping. The recommended temperature usage range for AP Armaflex® Pipe Insulation is -297°F to +220°F (-183°C to +105°C).
