Кислородный генератор PSA 2020 заполнение кислородом/азотом/аргоном/Co2 газом в

Описание и отзывы

Трекер стоимости

Характеристики



Item			Description	Remark
Power	220V/50Hz		100W	Power for Oxygen Generator
	220V/50Hz		60W	Power for Heatless Air Dryer
Environment Temperature			≤38℃(good ventilation)	/
Gas(PSA gas consumption)		Capacity	≥ 0.77Nm3/min (20℃,101.325kPa)	Air Compressor Output Requirements
		Pressure	≥ 0.7MPa
		Temperature	≤ 50 ℃
		Oil Content	≤ 3 PPm
		Dust Size	≤ 5 μm

oxygen capacity	2-200Nm3/h
oxygen purity	93%+-2%
output pressure	0.1-0.5MPa(1-5Bar) adjustable / 15MPa filling pressure offered



Specification	output (Nm³/h)	Effective gas consumption (Nm³/h)	air cleaning system
CBO-5	5	0.95	KJ-1
CBO-10	10	2.1	KJ-2
CBO-20	20	4.0	KJ-6
CBO-40	40	8.2	KJ-10
CBO-60	60	12.3	KJ-12
CBO-80	80	16.3	KJ-20
CBO-100	100	20.8	KJ-20
CBO-150	150	30.7	KJ-30
CBO-200	200	41	KJ-40



-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------





3. Process Flow Brief Description



4.Technical Features

 1).Full Automation

All systems are designed for un-attended operation and automatic Nitrogen demand adjustment.

 2).Lower Space Requirement

The design and Instrument makes the plant size very compact,assembly on skids,prefabricated from factory.

 3).Fast Start-up

Start-up time is only 5 minutes to get desired Nitrogen purity.So these units can be switched ON&OFF as per Nitrogen demand changes.

 4).High Reliabiity

Very reliable for continuous and steady operation with constant Nitrogen purity.Plant availability time is better than 99% always.

 5).Molecular Sieves life

Expected Molecular sieves life is around 15-years i.e. whole life time of nitrogen plant.So no replacement costs.

 6).Adjustable

By altering flow,you can deliver nitrogen with precisely the right purity.







 - It is an advanced technology with less investment.
- The quality is reliable and both the N2 purity and quantity are stable.
- The unit is supplied in a skid-mounted manner, which can be transported and installed easily.
- It is full automatic control and no need for operators, easy to start-up and shutdown, simplified and convenient maintenance.
- Our service department is formed by a skilled team of engineers. There are more than 15 of them, whose average age is about 35. We always adhere to the general principle of "good faith, high quality, innovation, and development ", and follow the idea of giving customers the maximum of satisfaction, which laid a good foundation to ensure that the service quality. We obtained loads of compliments for we not only guarantee the service quality, but also the benefits of customers.
- Free warranty for the equipments during the promised period
1. The nitrogen generator,1 year warranty, maintenance responding time is less than eight hours.
2. Ancillary equipment ,1 year warranty, maintance responding time is less than 8 hours.
3. Lifelong maintance service in a timely manner, the responding time is less than 8 hours.
4.Provide 24-hour hotline service. 0086-18757180256
5.Return visit every six months (callback or on the spot).
6.Supply accessories in a timely manner, the delivery time is generally 1-7 days.
7.Free repair at the expiry time of warranty





We have been making series of air separation units for nearly 20 years. With the support of a perfect management system and advanced manufacturing tools, we make constant technological improvements. We have built long-term good cooperation with many design and research institutes. Our air separation units have better and better performance.
