Механические втулки карбоновый графитовый вкладыш подшипник прокладка

Механические втулки карбоновый графитовый вкладыш подшипник прокладка

Категория: Other Graphite Products >>>
Поставщик: Zigong,Dongxin,Electrical,Carbon,Co.,ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.99 $*	0.95 $*
Aug-17-2025	0.57 $*	0.95 $*
Jul-17-2025	0.99 $*	0.20 $*
Jun-17-2025	0.45 $*	0.56 $*
May-17-2025	0.58 $*	0.3 $*
Apr-17-2025	0.3 $*	0.57 $*
Mar-17-2025	0.79 $*	0.27 $*
Feb-17-2025	0.24 $*	0.59 $*
Jan-17-2025	0.44 $*	0.54 $*

Характеристики

Mechanical Bushings Carbon Graphite Bush Bearing Gasket Washer Graphite

Product Describtion

Carbon graphite material for machines, with excellent self-lubrication, good resistance to chemical corrosion resistance, high thermal conductivity and thermal stability, enough mechanical strength, can be easily processed into all sorts of geometry shape products and be widely used in various mechanical equipments.

graphite carbon bearing 16

Impregnated object No. of mechanical carbon

Impregnated object name	Aluminium alloy	Babbit alloy	Copper alloy	Antimony	Furan resin	Phenolic resin	Sliver	Epoxy resin	Boron-impregnated silicate glass
Impregnated object No.	A	B	P	D	K	F	G	H	R

The description of mechanical sealing class series No.

Class	Series No.	Technical characteristics and application
Carbon—graphite material	1	With high mechanical strength and good wear resistance, and used for mechanical sealing, bearing and doctor blade etc.
Electrochemical graphite material	2	With higher mechanical strength and lubricity, good shock resistance, and used for mechanical, bearing etc. wear-resistant material.
Resin-carbon composite material	3	With high mechanical strength and good wear resistance, and used for mechanical sealing, bearing etc. wear-resistant material.
Metal graphite material	4	With high-temperature resistance, shock resistance and good heat-conducting performance, and used for the operating condition of high-temperature and higher shock load.
