Умный перистальтический насос с шаговым
- Категория: Pumps >>>
- Поставщик: Baoding,Chuangrui,Precision,Pump,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 60090.3 $* | 63095.52 $* |
| Aug-16-2025 | 59585.83 $* | 62564.2 $* |
| Jul-16-2025 | 49991.55 $* | 52491.67 $* |
| Jun-16-2025 | 58575.98 $* | 61504.80 $* |
| May-16-2025 | 51001.80 $* | 53551.25 $* |
| Apr-16-2025 | 57565.48 $* | 60443.76 $* |
| Mar-16-2025 | 57060.34 $* | 59913.18 $* |
| Feb-16-2025 | 56556.58 $* | 59384.48 $* |
| Jan-16-2025 | 56051.48 $* | 58854.93 $* |
Характеристики
Model: BT600FC/YZ1515x
Speed range: 0.1-600 rpm
Flow range : 0.007-2280 ml/min
Max Number of Channel: 2
Power supply: AC 110V or AC 220V
Ideal lab scale vials filling pump
With touch screen setting
With Calibration function to ensure the precise
Support foot pedal Control
Support hand dispenser
CE certified product based on request.
![]()
![]()
BT600FC is a intelligent touch screen peristaltic pump specially used for filling, with 3.5 inch touch screen which is easy operate and intelligent. It is very suitable for vial filling, can fill many kinds of liquid. The max flow rate is 2280ml/min. Can use multi pump heads such as YZ1515x, YZ2515x, TX315 and so on.
As a filling peristaltic pump, BT600FC Normally used in the fields such as Pharmaceutical filling peristaltic pump, Food filling pump, University laboratory, Water treatment pump , Cosmetic filling pump , Beverage filling pump, etc.
It is one of the most hot-selling models of CRPUMP, because there are many advantages such as the accuracy, handiness,easy-clean,ergonomic working, etc.
Except control it by the button, also support external control such as 0-5v, 0-10v,4-20mA, etc. Customers also can control the peristaltic pump by foot pedal. Support RS485 or RS232, just tell us which you want. There are professional R&D team which can customize according to customers’ requirement.
Parameter Model : BT600FC/YZ1515x | ||
Model | BT100M/YZ1515x | |
Speed | 0.1-600rpm | |
Speed resolution | 0.1rpm | |
Flow rate | 0.007-2280ml/min | |
Filling volume range | 0.1ml-9999L | |
Filling time range | 0.1s~9999min | |
Pause time range | 0.1s~9999min | |
Copy number | 0-9999 t | |
Power supply | AC220V±10%(standard) or AC110V±10%(optional) | |
External control | Start & stop, direction control, speed control( 0-5v, 0-10v, 4-20mA optional ) | |
Communication interface | RS232 and RS485, support MODBUS protocol mode | |
Foot pedal | Yes | |
Tube specifications for the pump head YZ1515x(black is defaulted) Noted : The standard tube which will come with the pump is model 18#, If you need other tube model , pls contact our sales in advance. | ||||||||
Tube model | ID(mm) | OD(mm) | Standard material | Flow range(ml/min) | ||||
18# | 7.9 | 11.1 | Silicon tube | 0.38-2280 | ||||
17# | 6.4 | 9.6 | Silicon tube | 0.29-1740 | ||||
25#
| 4.8 | 8 | Silicon tube
| 0.17-1020 | ||||
16#
| 3.2 | 6.4 | Silicon tube
| 0.082-492 | ||||
19#
| 2.4 | 5.6 | Silicon tube
| 0.051-306 | ||||
14#
| 1.6 | 4.8 | Silicon tube
| 0.027-162 | ||||
13#
| 0.8 | 4 | Silicon tube
| 0.007-42 | ||||
Pump head with PPS material (Black)
Pump head with PSF material (White)
Order guide
How to choose the suitable pump for your application ?Can you first to confirm some details as below :
1, What's your bottle's volume? ( )ml
2, How many channels you need? ( )
3,What kind of liquid you will dose ?is it corrosive ? ( )
Noted: The defaulted model we will send is 600FCB21 or 600FCB11. | |||||||||
Order number | Model | Pump head | Power supply | Channel number | Flow range with 18# tube | ||||
600FCB21 | BT600FC | YZ1515x(black) | AC220V | 1
| 0.38-2280ml/min | ||||
600FCB11 | OEM201-1 | AC110V | 1 | ||||||
600FCB22 | OEM201-1 | AC220V | 2 | ||||||
600FCB12 | OEM201-1 | AC110V | 2 | ||||||
Packing list | ||
1 | Pump :BT600FC/YZ1515x(black) | |
2 | Silicon tube: 18# 2 meters | |
3 | Power plug | |
4 | User manual | |
Weight | 8 KG | |
CTN MEAS | 36*25*36CM | |
Why choose this model for filling?
FC Intelligent dispensing peristaltic pumps on function is powerful：
·Storage function-user data storage function:(9 sets of filling data) . The original filling data can be quickly found by entering the storage interface with one key.
·External control function-Multiple mode selection: communication mode, analog mode，foot switch control.Provide customized services.
·Memory function-data will be stored in time after power off. When power supply is restored, the pump can remember the parameter Settings before power off, which is more safe and reliable.
·Calibration function-intelligent flow calibration: after setting the target flow, input the actual flow value,and the system will automatically carry out flow calibration to ensure the flow accuracy
·Full speed function-one button to control full speed operation, used for quick cleaning, filling and emptying tubes, etc
·Suckback function-By setting Suckback angle and Suckback speed to prevent liquid dripping and ensure fluid accuracy.
·lock screen function-lock screen design, error proof touch, application more secure.
·Display function-real-time animation of the operation interface shows the running state and working parameter.
·Touch-screen function-3.5-inch color LCD screen, (English and Chinese optional) , touch-screen operation,intuitive and
intelligent.
·Whole housing design-stainless steel housing，sturdy and durable , multi-face seamless whole housing design, Long service life,
·Storage function-user data storage function:(9 sets of filling data) . The original filling data can be quickly found by entering the storage interface with one key.
·External control function-Multiple mode selection: communication mode, analog mode，foot switch control.Provide customized services.
·Memory function-data will be stored in time after power off. When power supply is restored, the pump can remember the parameter Settings before power off, which is more safe and reliable.
·Calibration function-intelligent flow calibration: after setting the target flow, input the actual flow value,and the system will automatically carry out flow calibration to ensure the flow accuracy
·Full speed function-one button to control full speed operation, used for quick cleaning, filling and emptying tubes, etc
·Suckback function-By setting Suckback angle and Suckback speed to prevent liquid dripping and ensure fluid accuracy.
·lock screen function-lock screen design, error proof touch, application more secure.
·Display function-real-time animation of the operation interface shows the running state and working parameter.
·Touch-screen function-3.5-inch color LCD screen, (English and Chinese optional) , touch-screen operation,intuitive and
intelligent.
·Whole housing design-stainless steel housing，sturdy and durable , multi-face seamless whole housing design, Long service life,
Application
Peristaltic pumps are widely used in laboratories and scientific research institutions; chemical industry; construction industry; mining, metallurgy industry; paper industry; paint industry; food and beverage industry; ceramic industry; water treatment industry; bio pharmaceutical industry; agricultural hydroponics industry; Equipment industry; industrial washing machine matching; packaging machinery industry, etc.
![]()
Typical application for medium dispensing
Time quantitative medium dispensing pump with hand dispenser
Which with touch screen can set the vessel volume /filling time/pause time and medium qty you want to fill .
Support hand dispenser /foot pedal easy control.
Related Product
Model:UTF01
Channel: 4
Flow range: 0.007-2280ml/min/ channel
Model:SG600FC/YZ35-13
Channel: 1-2
Flow range:1.3-12000 ml/min
Model:BT100FC/YZ1515x
Channel: 1-2
Flow range :0.007-380 ml/min
Why Choose Us
![]()
![]()
![]()
![]()
![]()
![]()
Baoding Chuang Rui Precision Pump Co., Ltd. Started production of the peristaltic pump from 2006 . We are a innovative company focus on research and development, production and marketing of peristaltic pump.
We aim to “Produce CR pump to the easier life.
With 10 years professional experience of Peristaltic pump Tubing pump Liquid handling pump . Now we independent research and development of more than 30 series, over 200 kinds of products. We not only produce the standard peristaltic pump, Peristaltic pump filling system , but also focus on the ideal OEM design and customization. According to the actual needs of customers to produce the ideal OEM peristaltic pump .Widely used in various industries of pharmaceutical industry, fine chemical industry, environmental protection, biochemical industry, laboratory & research application etc.
We are confident that we can offer the top quality and service for our customers. And we are trying our best to be the top one in our peristaltic pump field.
Our professional team can insure fluent communication, as well as perfect after-sale service.
Chuang Rui make sure that our factory can supply peristaltic pump of best price, high quality, so you will be full of confidence for your market expansion.![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
We aim to “Produce CR pump to the easier life.
With 10 years professional experience of Peristaltic pump Tubing pump Liquid handling pump . Now we independent research and development of more than 30 series, over 200 kinds of products. We not only produce the standard peristaltic pump, Peristaltic pump filling system , but also focus on the ideal OEM design and customization. According to the actual needs of customers to produce the ideal OEM peristaltic pump .Widely used in various industries of pharmaceutical industry, fine chemical industry, environmental protection, biochemical industry, laboratory & research application etc.
We are confident that we can offer the top quality and service for our customers. And we are trying our best to be the top one in our peristaltic pump field.
Our professional team can insure fluent communication, as well as perfect after-sale service.
Chuang Rui make sure that our factory can supply peristaltic pump of best price, high quality, so you will be full of confidence for your market expansion.
CR Peristaltic pump is easy to maintenance
replaceable tubes allow you to switch from one liquid to another in the shortest amount of time.
No need to rinse and disassemble after the flushable product, you only need to replace the peristaltic pump tubing
CR Peristaltic pump with high precision
The calibration function can ensure the filling accuracy for each dose. The suck-back function prevents liquid (reverse): in the dispense mode, after the end of the direct cycle, the return stroke is initiated to prevent the liquid from flowing out of the pump tube during the stop.
CR peristaltic pump is non-pollution: the fluid only contacts the pump tube and does not touch the pump body;
CR Peristaltic pump is Versatility
CR peristaltic pump can be used with a variety of products and can be used in a variety of industries.
CR peristaltic pump is easy to work
After the power is turned off and on, the control system maintains the current settings (pump head tubing model and other parameters).
CR peristaltic pump with good sealing: It has the good self-priming ability and can be idling to prevent back flow.
CR peristaltic pump with Low shear: ideal for conveying shear sensitive, aggressive fluids
replaceable tubes allow you to switch from one liquid to another in the shortest amount of time.
No need to rinse and disassemble after the flushable product, you only need to replace the peristaltic pump tubing
CR Peristaltic pump with high precision
The calibration function can ensure the filling accuracy for each dose. The suck-back function prevents liquid (reverse): in the dispense mode, after the end of the direct cycle, the return stroke is initiated to prevent the liquid from flowing out of the pump tube during the stop.
CR peristaltic pump is non-pollution: the fluid only contacts the pump tube and does not touch the pump body;
CR Peristaltic pump is Versatility
CR peristaltic pump can be used with a variety of products and can be used in a variety of industries.
CR peristaltic pump is easy to work
After the power is turned off and on, the control system maintains the current settings (pump head tubing model and other parameters).
CR peristaltic pump with good sealing: It has the good self-priming ability and can be idling to prevent back flow.
CR peristaltic pump with Low shear: ideal for conveying shear sensitive, aggressive fluids
FAQ
We have professional support teams to assist with any queries you may have.
We have professional support teams to assist with any queries you may have.
Some frequently asked questions can be found below, however please do not hesitate to contact us with any specific questions.
Question 1: Can I order custom peristaltic pump with my own design & logo?
Answer: Definitely yes.
Question 2: Can I order a sample first before mass production? How can I place a sample order?
Answer: Surely you can order a sample first. And there will be some sample cost, charged based on your design. We will make the sample pump for you after payment received and take pictures for your reference once finished. If you want to see the actual sample, we can send the sample to you while freight cost is yours.
Question 3: How soon can I get a sample made? How can I make payment?
Answer: For simple design sample, it generally takes about 7-15 days to get samples made. While it will take a longer time for design, make a mold, assemble, actual test. etc. Payment can be made through T/T, paypal or Western Union.
Question 4: How can I get my peristaltic pump if I place the order to you?
Answer: That depends on the quantity your ordered. 1 to 100 pieces, the pumps will be shipped to you by express(DHL, Fedex, etc.); 100 or more, mostly by air or by sea.
Question 5: Can I buy the tube separately?
Answer: Of course Yes. for the silicone tube 15 meters per roll, or you can buy 1 or 2 meters. No problem.
