SD250 новая модель формовочной машины для изготовления кирпича

Clay brick machine is the smallest models brick extruders.

It is widely used in small family brick owners.Suitable for family workshops.

Also, its compact design makes machine operation very easily.

The SD-220 Brick Machine is suitable for making the clay brick adobe for house. The materials can be clay, black land, mixing clay etc. It includes Hopper, Mud pie cutter and Mud adobe slicer. It can be installed on the falsework(wooden/iron board), also can be installed on the concrete foundation.

SD220 machine is the fourth generation product of our factory which is designed after our technicians combine kinds of brick machines’ merits through many years’ production experience. It is the best one of the small type brick machine for the synthetic economic benefit at present. It is welded with profiled bar and all of its gears are made of 45# steel and alloy steel and through processing of Lathe for gear and quencher and cement ite quencher, then put into gear boxes. The running part of the machine is driven by bearing running and has air proof equipment for mud and water seal. The machine has the features of handsome shape, reasonable structure, good performance, high quality, smallness, lightness, high efficiency, durability, and convenience, and the user can use it everywhere and do not need a special place. The machine can be widely used and it is fit for clay, black earthly, mixed earth and so on. The machine is the best choice of brick equipment for small factories and professional individuals.

Production line for brick making machine

soil →feeding machine→ conveyor→the roller crushing mill→conveyor→ clay mixer →conveyor→clay brick making machine→green brick slitter→green brick cutting machine →plate for green brick

The whole machine is composed of Mud-mixer, Bar-cutter, Brick-cutting Lathe. The power enters from the head of the axis after the flat pulley and gears slow their speed. The earth with moderate humidity will be put into the hopper from the upper part of Mud-mixer, and fall into the Mud vat after it is crushed down, then it is puddled by Screw in the vat and put forwards. At last it is squeezed into standard mud bar from the entrance. Under the drive of the Screw, the mud bar enters into Bar-cutter and goes ahead on its board. When it comes to the proper place, the pull pole of the Bar-cutter is pulled to cut mud bar. When the cut mud bar comes to the right place of the brick-cutter, the control pole of the brick-cutter is held down to make the mud bar move on the slab ; so the mud bar is cut into standard brick, and then come to Brick-receiver.

Operation manual for brick molding machine

1.First add oil in the body before starting machine,run it as the arrow mark.

2.Upper 2 holes are the water line of brick mold,when mud strips come out normally,if the brick adobe angle is not smooth,slime angle,it has large difference with water.during testing it, open water when mud strips come out,then slowly close water to reach the satisfy for the smooth degree of mud strips,finally fix the water.(16 holes at sides can be blocked by cotton)

3.Hang steel wire for manual mud slicer.

4.Hang steel wire for brick adobe cutter.

Charactors of automatic concrete clay bricks hollow block making machine

1.Strong applicability, lower energy consumption,the extruder only 11 KW.

2.The raw material for making bricks can be soil,mud.

3.Solid brick is the best choice.

4.The brick extruder has taken manual brick strip cutter and brick blank cutter.

1.This clay brick making machine  is  suitable to make solid clay brick ,red clay brick ,red soil standard bricks, red mud brick etc, Different molds can bring out different brick.

2.The clay brick making machine material is rich and easy to find, such as Clay, shale, coal slack, fly ash etc It is very convenient to set up a factory and begin to make bricks.

3. This clay brick making machine has advantages of high production efficiency, compact structure, reliable performance, easy maintenance and steadily working without foundation bolt.

Advantages of brick making machine

The body of clay brick making machine  is made of castion.Processing mainshaft,mu pressing pallet bearing are made in the whole time.

1.Desinged to produce all kinds of hollow or solid brick & block by this clay brick making machine.

2.With all kind of raw material for making bricks:clay,shale ,coal slack, fly ash ,nud etc.

3.High efficiency and output;.good energy- saving,low cost and reliable.

4. Good stability,long service life about clay brick making machine.

Structure and Working Theory of brick making machine

The clay brick making machine is composed of Mud-mixer, Bar-cutter, Brick-cutting Lathe.

The power enters from the head of the axis after the flat pulley and gears slow their speed.

The earth with moderate humidity will be put into the hopper from the upper part of Mud-mixer, and fall into the Mud vat after it is crushed down, then it is puddled by Screw in the vat and put forwards. At last it is squeezed into standard mud bar from the entrance.Under the drive of the Screw, the mud bar enters into Bar-cutter and goes ahead on its board.

When clay  brick making machine comes to the proper place, the pull pole of the Bar-cutter is pulled to cut mud bar.

When the cut mud bar comes to the right place of the brick-cutter, the control pole of the brick-cutter is held down to make the mud bar move on the slab ; so the mud bar is cut into standard brick, and then come to Brick-receiver.
