5-тонный мини-кран-паук/гусеничный кран для узкого
- Категория: Другие краны >>>
- Поставщик: Henan,Anhuilong,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 3137823.47 $* | 3294714.73 $* |
| Aug-15-2025 | 3111455.46 $* | 3267028.28 $* |
| Jul-15-2025 | 2610458.57 $* | 2740981.56 $* |
| Jun-15-2025 | 3058718.72 $* | 3211654.37 $* |
| May-15-2025 | 2663194.45 $* | 2796354.58 $* |
| Apr-15-2025 | 3005982.56 $* | 3156281.45 $* |
| Mar-15-2025 | 2979613.47 $* | 3128594.37 $* |
| Feb-15-2025 | 2953245.20 $* | 3100907.31 $* |
| Jan-15-2025 | 2926877.83 $* | 3073221.92 $* |
Характеристики
The No. 1 spider crane Manufacturer of all the manufacturers in China.
SPECIFICATION
Technical data
|
Model |
HXB |
|
|
Crane capacity |
3.0t×1.3m |
|
|
Maximum working radius |
7.7m |
|
|
Maximum lifting height |
9.5m |
|
|
Winch |
Hook up speed |
2.8m/min(4 times) |
|
Diameter and length of wire rope |
Ø8mm×50m |
|
|
Telescopic |
Boom form |
4 (4 Automatic) |
|
Boom length |
8.2 m |
|
|
Derrick |
Derricking angle |
0-75° |
|
Slewing |
Slewing angle |
360-degree continuous |
|
Outrigger |
Form of outrigger |
First phase--automatic Second phase--manual |
|
Maximum extend range |
5.3m |
|
|
Traction system |
Travel |
Hydraulic |
|
Travel speed |
0-3.0km/h |
|
|
Track |
Synthetic rubber |
|
|
Gradeability |
30° |
|
|
Track ground pressure |
50kpa |
|
