Полностью автоматическая горизонтальная пресс-подборщик
- Категория: Другие упаковочные машины >>>
- Поставщик: Jiangsu,Xutian,Environmental,Protection,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 83300.78 $* | 87465.50 $* |
| Aug-19-2025 | 82600.81 $* | 86730.79 $* |
| Jul-19-2025 | 69300.31 $* | 72765.9 $* |
| Jun-19-2025 | 81200.4 $* | 85260.45 $* |
| May-19-2025 | 70700.25 $* | 74235.82 $* |
| Apr-19-2025 | 79800.76 $* | 83790.76 $* |
| Mar-19-2025 | 79100.24 $* | 83055.84 $* |
| Feb-19-2025 | 78400.29 $* | 82320.32 $* |
| Jan-19-2025 | 77700.64 $* | 81585.91 $* |
Характеристики
150T Full Automatic Horizontal Baling Press Baler Machine
Product Parameters
| Model | XTY-1500W110110-150 | XTY-1500W110125-150 | XTY-2000W110110L-180 | XTY-2000W110125L-180 |
| Pressure | 150tons | 150tons | 200tons | 200tons |
| Main Motor Power | 55kw*2 | 55kw*2 | 45kw*3 | 45kw*3 |
| Cooling System | water cooler | water cooler | water cooler | water cooler |
| Cycle Time (unload) | 12s | 12s | 11s | 11s |
| Oil Reservoir | 2600L | 2600L | 3500L | 3500L |
| Number of Belting | 5 lines | 5 lines | 5 lines | 5 lines |
| Wire Size | Ø 3.4-3.6 | Ø 3.4-3.6 | Ø 3.4-3.6 | Ø 3.4-3.6 |
| Feed Opening Size (L*W) | 2000*1050mm | 2000*1050mm | 2200*1050mm | 2200*1050mm |
| Chamber Size(L*W*H) | 2600*1100*1100mm | 2600*1100*1250mm | 2800*1100*1100mm | 2800*1100*1250mm |
| Bale Size (L*W*H,L can be adjustable) | L*1100*1100mm | L*1100*1250mm | L*1100*1100mm | L*1100*1250mm |
| Bale Density(OCC) | 550-600kgs/m3 | 550-600kgs/m3 | 550-600kgs/m3 | 550-600kgs/m3 |
| Throughput(30-60 kgs/m3) | 15-20tons/h | 17-25tons/h | 19-28tons/h | 20-30tons/h |
| Machine Weight | 30tons | 32tons | 34tons | 35tons |
| Machine Overall Dimension | 11600*4200*6000mm | 11600*4200*6000mm | 12000*4200*6000mm | 1200*4200*6000mm |
| Tying | Horizontal Tying or Vertical Tying | |||
| Feeding Device | Conveyor | Conveyor | Conveyor | Conveyor |
| Conveyor | ||||
| Feeding Width | 2000mm | 2000mm | 2200mm | 2200mm |
| Speed | 0-12m/min | 0-12m/min | 0-12m/min | 0-12m/min |
| Power | 11kw | 11kw | 11kw | 11kw |
| Weight | 14tons | 14tons | 14tons | 14tons |
| Overall Dimension | 16000*2400*6200mm | 16000*2400*6200mm | 16000*2600*6200mm | 16000*2600*6200mm |
| Used for newspaper | ||||
| Motor | 15kw | 15kw | 15kw | 15kw |
Product Features
Features of Large-sized Full Automatic Balers
· Photoelectric switch activates baler when charge box is full
· Unique double-cutting design of cutters improves the cutting efficiency and lengthens the lifespan of the cutters
· Particular anti-slide design of the machine makes nicer bales
· Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals
· Equipped with rapid automatic tying system, easy for cleaning and maintaining
· Use differential technique for the hydraulic system, makes shorter cycle time so that improve the working efficiency and save electricity
· Automatic tension system ensures “brick-like” bales on all loose materials.
· Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient
· Automatically detect and show the errors of the machine which improve the machine inspection efficiency
· International standard electric circuit layout, graphic operation instruction and detailed parts marks makes the operation been more easily understanding and improves the maintenance efficiency
· The press heads are specially processed by planomiller, ensures the precise running of the ram
· Use high quality hydraulic system from Taiwan, ensures the stable running of the machine
· The heavy duty machine body makes sure only flat ground is required by the installation
Usage of Large-sized Full Automatic Balers
Specialized in recycling and compressing the loose materials like waste paper, cardboards/cartons, cartons trims, waste books, magazines, plastic film and straw etc.
Product Details
Main Products
Company Profile
Production Process
Transport
Contact US
Q:Why use a baler?
A:In order to effiectively handle your recyclable waste or resources,you need a baling machine to compress the waste material into baler.neat and tidy bales not only reduce your storage space,it also reduces your transportation cost because you can certainly load more cardboard bales into a container or truck as compared to the lose ones.
Q:Who use a baler?
A:Shopping malls,retail stores ,grocery stores,marine vessels,need baling machine to help them compact the waste such as cartons,cardboards plastic films,so that they can be stored easily before selling to recycling plant.Corrugating and printing company,need baling to compact the waste paper trims. Recycling plants needs baling machine to compact into small bales for easy transportation and save cost.
Q:Where to buy a suitable baler?
A:XTpack is a baling machine manufacture for more than 15 years with CE and XT pack website,can help you narrow down which hydraulic baling presses are idea to bale the waste material you are handling as well as matching it to your expected output capacity. You can choose our stand ardmodels and we can also provide customized baling machine.
Q:How to choose a suitable baler?
A:a.Type of material you will be baling.For example,if you need a baling press to bale plastic,you should specify the exact type of plastic .-ie PET bottles ?HDPE containers plastic bags ?Plastic film? b.Bale size and output requirement say how many tons per day or per hour?
