High capacity fiber ball machine

Cotton ball machine mainly used to form a beautiful appearance ball shape products, the machine is safety and stability of operations, and facilitate hoisting and installation.

The process usually need two machine

1.Cotton opening machine

2.Fiber ball machine

After PP cotton being opened,then it can process to ball shape products.

Application of fiber ball machine

Can use in Cloth,sofa,cushion,quilt,pillow inner,toy,Which make sure the surface looks full,more beautiful,flexiable,the machine can adjust the ball size,and loose condition,to meet different requirement of polyester ball.



Features of fiber ball machine

1.High production,Single phase cotton ball machine 50-100kg/h,three phase KY-2  with capacity

120-180kg/h,only need 1-2 workers.
2.Cotton break and molding automatically.
3.Ball size can be adjustable from 0.2g to 3g
4.Machine with Electrical cluth control system.
5.Low noise and work stable only occupy small area.
6.Equiped Touch screen which is easy to operate.

Model	BY-100	BY-200
Power	3kw+2.2kw	7.5kw+2.2kw
Capacity	30-50kg/h	120-180kg/h
Voltage	220V/ 50Hz/1phase	380V/ 50Hz/3phase
Dimension	2100*1000*750mm	2100*1000*750mm
Ball size	0.2-3g adjustable	0.2-3g adjustable
