Характеристики
Shanghai heavy duty new condition flat bed road wrecker tow truck with Crane for sale
Product Description
A,Working Condition
1,Altitude: 0-4500m
2,Temperature: -35℃--+45℃
3,Relative humidity: 80%
4,Wind force: ≤8degree
B,Working Range
KFM5442TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.
C,Main Parameters
| Items | Unit | Value | |
| Lifting Structure | Rated Lifting weight | kg | 13765 |
| Max. Lifting weight of original place | kg | 18000 | |
| Max. Lifting weight of full extension boom | kg | 8000 | |
| Rated towing weight | kg | 44000 | |
| Max. Designed towing weight | kg | 60000 | |
| Effective length of boom | mm | 3350 | |
| Extension traveling of boom | mm | 1700 | |
| Folding angle of boom | ° | 90 | |
| Under lift Structure | Max. Rated hanging weight | kg | 25000 |
| The height from hook to the ground | mm | 13430 | |
| Max. Extension traveling of lifting boom | mm | 6000 | |
| Rotation angle | ° | 360 | |
| Numbers of winch | piece | 2 | |
| Rated pulling power of winch | kg | 2×15000 | |
| Dia. Of steel cable | mm | 22.4 | |
| Length of steel cable | m | 40 | |
| Min. Speed of steel cable | m/min | 4 | |
| Rotation angle | ° | 65 | |
| Vehicle | External dimension | mm | 10741×2500×3366 |
| Parameters | Chassis model | FM400 84RB | |
| Drive | 8×4 | ||
| Axle base | mm | 1995+4405+1370 | |
| The whole weight of empty load | kg | 30040 | |
| Load of front axle of empty load | kg | 14380 | |
| Load of rear axle of empty load | kg | 15660 | |
| The whole weight of full load | kg | 44000 | |
| Load of front axle of full load | kg | 9000/9000 | |
| Load of rear axle of full load | kg | 13000/13000 | |
| Wheel base (front/rear axle) | mm | 2019/1834 | |
| Front suspension | mm | 1362 | |
| Rear suspension | mm | 935 | |
| Approach angle | º | 16.6 | |
| Departure angle | º | 20 | |
| Min. Turning diameter | m | 24.6 | |
| Min. Ground clearance | mm | 306 | |
| Max. Speed | km/h | 99 | |
| Grade ability | % | 30 | |
| Gas consumption per one hundred miles(diesel oil) | L | 35.4 | |
| Engine model | - | D13 | |
| Engine emission | L | 12.8 | |
| Rated power | kw/r/min | 400/294/1400~1800 | |
| Torque | n·m/r/min | 2000/1050~1400 | |
| Fuel type | Diesel | ||
| Standard of emission | EN III | ||
| Tire size | 315/80R22.5 | ||
| Persons | 3 | ||
D,Standard Equipments
1. VOLVO FM400 84RB
2. Main boom structure assembly
3. Vice boom assembly
4. Hanging hook assembly
5. Control structure assembly
6. Chain wheel and hanging assembly
7. Winch assembly (include winch clutch, impaction device)
8. Steel body assembly
9. Tool box assembly
10. Light stands assembly
11. Alarm device
12. Hydraulic system
13. Hydraulic system over voltage protection device
14. Electric system
15. PTO Warner
16. Combination lamps
17. Hydraulic duel rear outrigger assembly
18. Lifting assembly
19. Y wheel lift
20. Steel wire rope
21. Output of electronic device
22. Standard spare tire
23. Safety chains
24. Vulnerable parts attachment
FAQ
1, Q: Why should we choose you ?
A: We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.B: We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.
C: We have our own R&D team, production workshop, QC management team, international marketing team and after service team.
D: We will provide the most professional and the best service on every business discussion and operation procedure.
E: We can provide special design for different specification requirement according to different orders or tender documents.
G: We have jointed ventures with Morita for 4 years, so the technology, design and quality are same with Morita.
H: We have collaboration with various top enterprises of fire protection sector, Such as Darley, Rosenbauer, HALE, AKRON, Ekhart, etc.
I: Our Certifications: ISO, TUV, CCCF, SONCAP, CNAS, SGS,MH /T5002-9, MEP, CQC.
2, Q: What's your Payment method?
A: T/T 30% deposit, balance will be paid by T/T before delivery
B: 100% L/C before start production
3, Q: What logistics ways we can work for shipment?
A:We can ship fire trucks by various transportation tools
B:We will go by sea to all main continents such as South America, Middle East, Africa, Oceania and Europe etc.
4, Q: What's the delivery time?
A: 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
B: ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
C: European brand chassis 9 months upon receipt of advance deposit.
5, Q: Can you provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting fire trucks for years. Rich experience for exporting to different countries like African mark.
A: 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
B: ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
C: European brand chassis 9 months upon receipt of advance deposit.
5, Q: Can you provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting fire trucks for years. Rich experience for exporting to different countries like African mark.
Product Process
Certifications
Packaging & Shipping
Company Information
Shanghai Jindun is a professional fire protection enterprise,one of the largest fire protection equipment and fire fighting vehicle manufacturer.Our company owns a first-rate ultra-large modern factory, internationally advanced processing equipment, domestic and foreign sales networks and a powerful service system, gathers many top technicians and industrial experts, and has 112 types of products, including CAFS fire trucks, water tank foam trucks, rescue vehicles, gas supply vehicles and other general fire trucks.Our Company will give you best products and best service.
