 used automatic computerized rotogravure printing machine japan









1. Main parameter:



1. Printing colors: 6 color 8 groups



2. Max.width of printing material: 830mm



3. Max. Printing width: 800mm



4. Max. Mechanical speed: 120m/min.



5. Max. Printing speed:10-100m/min(varies according to the different printing



                         ink and the familiarity of the operator.etc).



6. The Max diameter of unwind and rewind: 600mm.



7. Diameter of printing cylinder: 100mm-380mm.



8. Precision of overprint: longitudinal register≤±0.15mm



                       Horizontal register≤±0.15mm



9. Diameter of web: 76mm (inner)*92mm (outer).



10. Main motor: frequency conversion motor   7.5KW



11. Machine power: 46kw



12. Overall dimension: 9500×2400×2520mm



13. Net weight: 8T



14. Printing material:



Non-woven



Cellophane: 20-30μm



PET: 12-60μm



PE: 40-80μm



OPP: 15-60 μm



BOPP: 15-60 μm



CPP: 15-60 μm



PVC:20-80μm



NY: 15-50μm



PAPER: 30-80gsm



Composite film: 15-60μm



And other film materials with the similar printing performance listed above.



2. Unwind unit



Structure:

(1) Double-armed working mechanism rotation whirling stand. ( Electric flip)

(2) The rotation of unwind stand by torque motor: 0.37kw

(3) Adopt with magnet powder brake: 25N.M

(4) Adopt with auto tension controller

Specification:

(1) Horizontal adjustment of printing material manually: ±20mm

(2) Tension control range: 3-25kg.

(3) Air shafts: 3 inch (76mm).

(4) Max.diameter of unwind: 600mm



3. Printing unit



3.1 Printing pressure structure

(1) Printing pressure method: double air cylinder pressure.

(2) Printing pressure roller: rubber roller, Ø120mm.

(3) Max.printing pressure: 300kg , the pressure adjustable.

(4) Cylinder installation: shaftless type; by pneumatic

(5) Max.length of the printing cylinder: 380mm to 830mm.



3.2 Doctor blade

(1). Doctor blade with pneumatic type, with adjustable pressure.

(2) The horizontal direction,vertical direction and its angle can be adjust.

(3) The movement of the doctor blade: ±2.5mm

(4) The doctor blade pressure: 10-100kg.



3.3 Ink stand

(1) Ink stand up and down in vertical direction, adjusted by handwheel.

(2) printing cylinder directly dipped into the ink dish.

(3) The max.depth of the printing cylinder dipped into the ink: 50mm.

(4) Ink dish: made of stainless steel.



3.4 Ink recycle system

Each printing unit has one ink pump



3.5. Drying oven part

Structure:

(1) Each unit has a separating drying system.

(2) Sealed oven type which saves energy.

(3) Drying method: Electric heating.

(4) Heating power: 7kw

(5) Heating temper: automatic constant temper control (each printing unit)

(6) Blower: centrifugal blower (each printing unit)



Accessories list
NO	name	specification	unit	quantity	remark
1	Double sided spanner	12x14	PCS	1
2	Double sided spanner	17x19	PCS	1
3	Double sided spanner	22x24	PCS	1
4	Double sided spanner	27x30	PCS	1
5	Taper bushings	70MM &100MM	SET	4	Each size two sets( one short and one long type)
6	Inner hexagon spanner		SET	1
7	“-“ spanner		PCS	1
8	Hard blade		SET	1
9	Ink stirring bar		SET	1
10	Pressure Rubber roller	800mm	SET	1
11	Pressure rubber roller	600mm	SET	1
12	Ink dish	890mm	SET	1
13	Ink dish	690mm	SET	1
14	Ink blade		SET	1
15	Air compressor		PCS	1
16	Ink pump		PCS	10
17	Grip wrench		PCS	1
18	tube		PCS	1
