Фильтры-INGERSOLL RAND: высокотемпературный фильтр Ingersoll Rand filter high temperatureIngersoll high-pressure filterIR FILTERS advanced compressed air filters reduce contamination in your stream to help protect critical
- Категория: >>>
- Поставщик: Shanghai,Compressor,Service,Co.,Ltd.,[Shanghai,China]Shanghai
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 18802.78 $* | 19178.93 $* |
| Jul-15-2025 | 15249.25 $* | 15554.27 $* |
| Jun-15-2025 | 18506.46 $* | 18876.65 $* |
| May-15-2025 | 18358.46 $* | 18725.88 $* |
| Apr-15-2025 | 14657.58 $* | 14950.83 $* |
| Mar-15-2025 | 18062.84 $* | 18423.98 $* |
| Feb-15-2025 | 17914.22 $* | 18272.52 $* |
| Jan-15-2025 | 17766.41 $* | 18121.32 $* |
Характеристики
FILTERS - INGERSOLL RAND: ![]()
Ingersoll Rand filter, high temperature
Operating conditions:
- Max. operating pressure: 17 bar (g)
- Max. operating temperature: 150°C
- Irregular operating temperature (10% of the working hours): 200°C
- Min. operating temperature: 1°C
- Complies with PED 97/23/EC and CE
Type G - Particle:
- Air quality acc. ISO 8573.1:2001/Class 3 particles/Class 3 oil
- Removes particles down to 1 micron
- Maximum residue of liquid water and oil: 0.6 mg /m3 at 21°C
Type H - capacity oil filter:
- Air quality acc. ISO 8573.1:2001/Class 2 particles/Class 1 oil
- Removes particles down to 0.01 micron
- Maximum residual oil aerosol: 0.01 mg/m3 at 21°C
Type D - Dust:
- Air quality acc. ISO 8573.1:2001/Class 3 particles
- Removes particles down to 1 micron
NB: All models are available with different elements (G, H, D)
Ingersoll Rand micro filter (high temperature), G, H or D:
Model G/H/D | Capacity m3/min. at 7 bar | Air connection BSPT | W/H mm. | Weight kg |
| F024I (quality) HDT | 0.40 | 3/8" | 94/210 | 1 |
| F048I (quality) HDT | 0.80 | 1/2" | 94/210 | 1 |
| F096I (quality) HDT | 1.60 | 3/4" | 94/280 | 1 |
| F0150I (quality) HDT | 2.50 | 1" | 120/700 | 4 |
| F0300I (quality) HDT | 5.00 | 1" | 120/700 | 4 |
| F0500I (quality) HDT | 8.33 | 1 1/2" | 120/700 | 4 |
| F0800I (quality) HDT | 13.33 | 2" | 170/970 | 9 |
| F1000I (quality) HDT | 16.67 | 2" | 170/970 | 9 |
| F1300I (quality) HDT | 21.67 | 2 1/2" | 200/1020 | 14 |
| F2000I (quality) HDT | 33.33 | 3" | 200/1300 | 17 |
| F2700I (quality) HDT | 45.00 | 3" | 200/1300 | 17 |
FILTERS - INGERSOLL RAND:
Ingersoll Rand high-pressure filter
Type G – Particle filter
- Air quality acc. ISO 8573.1:2001/Class 3 particles/Class 3 oil
- Removes particles down to 1 micron
- Maximum residue of liquid water and oil 0.6 mg/m3 at 21°C
Type H - High capacity oil filter:
- Air quality acc. ISO 8573.1:2001/Class 2 particles/Class 1 oil
- Removes particles down to 0.01 micron
- Maximum residual oil aerosol 0.01 mg/m3 at 21°C
Type D – Dust filter:
- Air quality acc. ISO 8573.1:2001/Class 3 particles
- Removes particles down to 1 micron
Type A - Activated carbon filter:
- Air quality acc. ISO 8573.1: 2001/Class 1 oil
- Removes odours from oil vapors
- Maximum residual oil vapors: 0.003 mg/m3 at 21°C
Operating Conditions
- Max. operating pressure: 40 bar (g)
- Max. operating temperature: 80°C
- Min. operating temperature: 1°C
- Complies with PED 97/23/EC and CE
NB: All models are available with different elements (G, H, D, A)
Ingersoll Rand filter, high pressure G/H/D/A:
Model G/H/D/A | Capacity m3/min at 7 bar. | Capacity m3/min at 40 bar. | Air connection BSPT | W/H mm. | Weight kg. |
| F0150I (quality) HDP | 2.50 | 12.50 | 1" | 120/435 | 3 |
| F0300I (quality) HDP | 5.00 | 25.00 | 1" | 120/435 | 3 |
| F0500I (quality) HDP | 8.33 | 41.67 | 1 1/2" | 120/435 | 3 |
| F0800I (quality) HDP | 13.33 | 66.67 | 2" | 170/705 | 8 |
| F1000I (quality) HDP | 16.67 | 83.33 | 2" | 170/705 | 8 |
| F1300I (quality) HDP | 21.67 | 108.33 | 2 1/2" | 200/755 | 12 |
| F2000I (quality) HDP | 33.33 | 166.67 | 3" | 200/1035 | 16 |
| F2700I (quality) HDP | 45.00 | 225.00 | 3" | 200/1035 | 16 |
IRAC424 IRDP424 IRGP424 IRHE424 IRAC669 IRDP669 IRGP669 IRHE669 IRAC1314 IRDP1314 IRGP1314 IRHE1314 IRAC1980 IRDP1980 IRGP1980 IRHE1980 IRAC2119 IRDP2119 IRGP2119 IRHE2119 IRAC2755 IRDP2755 IRGP2755 IRHE2755 IRAC4132 IRDP4132 IRGP4132 IRHE4132 IRAC6886 IRDP6886 IRGP6886 IRHE6886 IRAC11018 IRDP11018 IRGP11018 IRHE11018 IRAC16527 IRDP16527 IRGP16527 IRHE16527
Ingersoll Rand inline air filter
Compressed air filter
plz contact me for more information and exact price
IR FILTERS advanced compressed air filters reduce contamination in your air stream to help protect critical processes and valuable equipment. Rigorously tested and engineered with superior components, F-Series filters will provide years of reliable performance and consistently high quality air.
Features:
- Accurate Information: Patented dual indicator shows differential pressure drop and operating efficiency
- Rugged Design: All-aluminum, precision die cast body suitable for 176 F / 80 C and 250 psig / 17.2 bar MAWP applications
- Reliable Operation: Filter element with stainless steel mesh withstands high pressure and minimizes flow restriction
- Easy Maintenance: Ergonomic bowl design with no-touch filter simplifies element replacement
- Lone Element Life: Proprietary media coating technology protects against corrosion and increases element life
A | Patented dual indicator shows differential pressure drop and economical operating efficiency |
B | Patented smooth bore flow insert directs air into the filter element, minimizing turbulence and pressure losses |
C | All-aluminum, precision die cast body suitable for 80°C (176°F) and 17 bar g (250 psig)MAWP applications |
D | Proprietary coating applied to the inside and outside surfaces provides corrosion protection in harsh industrial environments |
E | Filter element with stainless steel mesh withstands high differential pressure while minimizing flow restriction through the element |
F | Ergonomic bowl design with no-touch filter element simples element replacement |
G | Time strip label indicates when it's time to change the element (A Grade only) |
H | Industrial-grade brass float drain discharges accumulated condensate and oil more reliably than lesser quality plastic drains (no-loss and manual drains also available) |
I | Deep-pleated filter media reduces air flow velocity to maximize filtration efficiency and minimize pressure losses |
J | High-efficiency drainage layer improves liquid drainage properties and enhances chemical compatibility |
K | Simple visual alignment of the filter head and bowl ensures accurate assembly of components and helps to improve safety |
Specification
| MODEL | CAPACITY | Dimension (mm) | WEIGHT | ||||
| m3/hr | m3/min | A | B | C | D | Kg | |
| IRAC1980-18 | 1980 | 55.77 | 450 | 201 | 1140 | 650 | 95 |
| IRDP1980-18 | |||||||
| IRGP1980-18 | |||||||
| IRHE1980-18 | |||||||
| IRAC 2119-18 | 2119 | 59.97 | 450 | 201 | 1140 | 650 | 95 |
| IRDP 2119-18 | |||||||
| IRGP 2119-18 | |||||||
| IRHE 2119-18 | |||||||
| IRAC 2755-18 | 2755 | 77.97 | 500 | 230 | 1220 | 650 | 135 |
| IRDP 2755-18 | |||||||
| IRGP 2755-18 | |||||||
| IRHE 2755-18 | |||||||
| IRAC 4132-18 | 4132 | 116.94 | 580 | 273 | 1294 | 650 | 177 |
| IRDP 4132-18 | |||||||
| IRGP 4132-18 | |||||||
| IRHE 4132-18 | |||||||
| IRAC 6886-18 | 6886 | 194.87 | 750 | 361 | 1519 | 650 | 368 |
| IRDP 6886-18 | |||||||
| IRGP 6886-18 | |||||||
| IRHE 6886-18 | |||||||
| IRAC 11018-18 | 11018 | 311.81 | 740 | 410 | 1884 | 800 | 515 |
| IRDP 11018-18 | |||||||
| IRGP 11018-18 | |||||||
| IRHE 11018-18 | |||||||
| IRAC 16527-18 | 16527 | 467.71 | 1000 | 485 | 1777 | 850 | 684 |
| IRDP 16527-18 | |||||||
| IRGP 16527-18 | |||||||
| IRHE 16527-18 | |||||||
