Hot Selling China Voltage Stabilizer with CE Certificate

Description:
Three phase voltage stabilizers is designed for stabilizing AC voltage and made with Western Europe advanced technology and on the basis of our country national conditions. Three phase voltage stabilizer can keep output voltage in steady state automatically when the power voltage fluctuates or the load current varies.

Compared with other voltage stabilizers, it has the advantage of large capacity, high efficiency, no wave distortion, stable voltage adjustment, suitability for kinds of loads, bearing instantaneous overload, working continually for long time, as well as free transferring between manual control and automatic control, etc, besides, the three phase voltage stabilizer is provided with protection against over-voltage, over current, phase failure and protection for phase sequence and has following merits: small volume, light weight, convenient installation and reliable running and so on.



Application:
The three phase voltage stabilizer can be applied to large type electromechanical equipment, metal processing equipment, production line, construction device , elevator, medical equipment, equipment of light and textile industry, air-condition, TV set, household appliance and lighting used for industry, agriculture, traffic, military, railroad, scientific culture, etc, where need voltage stabilization.



Service Conditions:
1. The product is used indoors;
2. Temperature environment: -15℃~+40℃;
3. Altitude:<1,000 m;
4. Relative humidity: 90% ;
5. No gas, steam, chemical precipitate, dust, dirt or any explosive or corrosive medium, which can seriously affect the insulation of voltage stabilizer in the installation place.
6. No serious vibration or jolt in the installation place.



Main Technical Data
Input voltage	Three-phase: three-phase four-wire phase voltage 220±20%,wire voltage 380V±20% or phase voltage 220±30%, wire voltage 380V±30%, they can be selected (please indicate when placing an order) Single phase: 220V±20% or 220V±30%, it can be selected ( please indicate when placing an order).
Output voltage	Three-phase: three-phase four-wire phase voltage 220V, wire voltage 380V Single-phase: 220V
Accuracy of output voltage	2-5% (adjustable)
Efficiency	≥95% ( power class: more than 50KVA)
Response speed	1.5S (when outside voltage has 10% of change)
Waveform distortion	no additive waveform distortion
Protection	protection against over voltage, over current, phase failure and machine fault, as well as phase sequence protection (single-phase and three-phase 150KVA below has no phase failure and is provided with phase sequence protection)
Voltage stabilization, convenient switching for commercial power (single phase has no function)
Start automatically or by hand (can be chosen) when power is on. Can work continuously for a long time without anybody attendance.
Insulation resistance	≥2MΩ
Electric strength	bear power frequency sine voltage 2,000V for 1 min without breakdown or flash over. Overload capability: 2 times rated current, keeping 1 min (voltage stabilizer special for elevator and CT)
