Характеристики


FILTERS - INGERSOLL RAND:

Ingersoll Rand filter incl. flange



Type G – Particle filter:

  • Air quality acc. ISO 8573.1:2001/Class 3 particles/Class 3 oil
  • Particle removal down to 1 micron
  • Maximum residual oil aerosol: 0.6 mg/m3 at 21°C
  • Operating conditions:
    - Max. Operating pressure: 16 bar (g)
    - Max. Operating temperature: 80°C
    - Min. Operating temperature: 1°C
  • Complies with PED 97/23/EC and CE

Type H – High capacity oil filter:

  • Air quality acc. ISO 8573.1:2001/Class 2 particles/Class 1 oil
  • Particle removal down to 0.01 micron
  • Maximum residual oil aerosol 0.01 mg/m3 at 21°C
  • Operating conditions:
    - Max. Operating pressure: 16 bar (g)
    - Max. Operating temperature: 80°C
    - Min. Operating temperature: 1°C
  • Complies with PED 97/23/EC and CE
  • Note: The H-filter must be a corresponding G-filter

Type D – Dust filter:

  • Air quality acc. ISO 8573.1:2001/Class 3 particles
  • Particle removal down to 1 micron
  • Operating conditions:
    - Max. Operating pressure: 16 bar (g)
    - Max. Operating temperature: 80°C
    - Min. Operating temperature: 1°C
  • Complies with PED 97/23/EC and CE

Type A - Activated carbon filter:

  • Air quality acc. ISO 8573.1:2001/Class 1 oil
  • Removes odors from oil vapors
  • Maximum residual oil vapors: 0.003 mg/m3 at 21°C
  • Operating conditions:
    - Max. Operating pressure: 16 bar (g)
    - Max. Operating temperature: 30°C
    - Min. Operating temperature: 1°C
  • Complies with PED 97/23/EC and CE

NB: F0770I to F2100I is made from aluminum and F2800I to F31000I is made from cast iron. All models are available either with Float Drain (G, H, D, A) or Electronic No Loss Drain (GE, HE, DE, AE)



Ingersoll Rand filter incl. flange, G, H, D, A/GE, HE, DE, AE:



Model G,H,D,A /

GE,HE,DE,AE

Capacity

 m3/min. at 7 bar

 Connection,

 float drain

 Connection,

no loss drain

 W/H

mm.

 Weight

kg

 F0770I 12.80 DN 050 DN 040 285/500 8
 F1320I 22.00   DN 065 DN 050 285/690 11
 F2100I 35.00   DN 080 DN 080 340/880 16
 F2800I 46.70 DN 100 DN 100 485/1264 125
 F4200I 70.00 DN 125 DN 125 630/1274 196
 F5700I 95.00 DN 150 DN 150 630/1384 210
 F7500I 125.00   DN 150 DN 150 676/1434 264
 F9300I 155.00  DN 175 DN 175 724/1503 214
 F11000I 183.30  DN 200 DN 200 724/1503 320
 F14200I 236.70 DN 200 DN 200 885/1565 530
 F19900I 331.70 DN 250 DN 250 950/1573 670
 F31000I 516.70 DN 300 DN 300 1050/1702  1083



88 CFM High Efficiency Filter | Ingersoll Rand FA150IH

  • Air System Design Capacity:  88 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.01 ppm
    • Particle Filtration = 0.01 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  5.1″ L x 5.1″ W x 12.6″ H
  • Connection Size:  1″ NPT
  • Shipping Weight:  4.5 Lbs

88 CFM General Purpose Coalescing Filter | Ingersoll Rand FA150IG

  • Air System Design Capacity:  88 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.1 ppm
    • Particle Filtration = 1 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  5.1″ L x 5.1″ W x 12.6″ H
  • Connection Size:  1″ NPT
  • Shipping Weight:  4.5 Lbs

710 CFM High Efficiency Filter | Ingersoll Rand FA1200IH

  • Air System Design Capacity:  710 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.01 ppm
    • Particle Filtration = 0.01 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  8.1″ L x 8.1″ W x 23.5″ H
  • Connection Size:  3″ NPT
  • Shipping Weight:  20.5 Lbs

710 CFM General Purpose Coalescing Filter | Ingersoll Rand FA1200IG)

  • Air System Design Capacity:  710 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.1 ppm
    • Particle Filtration = 1 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  8.1″ L x 8.1″ W x 23.5″ H
  • Connection Size:  3″ NPT
  • Shipping Weight:  20.5 Lbs

65 CFM High Efficiency Filter | Ingersoll Rand FA110IH



PERFORMANCE & DIMENSIONS

  • Air System Design Capacity:  65 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.01 ppm
    • Particle Filtration = 0.01 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  3.9″ L x 3.9″ W x 10.9″ H
  • Connection Size:  3/4″ NPT
  • Shipping Weight:  2.4 Lbs

65 CFM General Purpose Coalescing Filter | Ingersoll Rand FA110IG



PERFORMANCE & DIMENSIONS

  • Air System Design Capacity:  65 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.1 ppm
    • Particle Filtration = 1 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  3.9″ L x 3.9″ W x 10.9″ H
  • Connection Size:  3/4″ NPT
  • Shipping Weight:  2.4 Lbs

600 CFM High Efficiency Filter | Ingersoll Rand FA1000IH



PERFORMANCE & DIMENSIONS

  • Air System Design Capacity:  600 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.01 ppm
    • Particle Filtration = 0.01 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  6.7″ L x 6.7″ W x 20.4″ H
  • Connection Size:  2″ NPT
  • Shipping Weight:  11.5 Lbs

600 CFM General Purpose Coalescing Filter | Ingersoll Rand FA1000IG



G – Series     |     0.1 ppm (Oil)  & 1 micron (Particulate) Filter rating

H – Series     |     0.01 ppm (Oil) & 0.01 micron (Particulate) Filter rating

D – Series     |     1 micron (Particulate) Filter rating

A – Series     |      0.003 ppm (Oil Vapor – Carbon) Filter rating

PERFORMANCE & DIMENSIONS

  • Air System Design Capacity:  600 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.1 ppm
    • Particle Filtration = 1 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  6.7″ L x 6.7″ W x 20.4″ H
  • Connection Size:  2″ NPT
  • Shipping Weight:  11.5 Lbs









FA800I

Grade:A G H D

FA800IA   FA800ID   FA800IG   FA800IH

Ingersoll Rand inline air filter

Compressed air filter

470 CFM High Efficiency Filter | Ingersoll Rand FA800IH



PERFORMANCE & DIMENSIONS

  • Air System Design Capacity:  470 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.01 ppm
    • Particle Filtration = 0.01 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  6.7″ L x 6.7″ W x 20.4″ H
  • Connection Size:  2″ NPT
  • Shipping Weight:  11.5 Lbs
  • ISO Certification
    • ISO 8573-2
    • ISO 12500
  • SKU Part # FA800IH


470 CFM General Purpose Coalescing Filter | Ingersoll Rand FA800IG



FA-(G) (H) (D) (A) Series Compressed Air Line Filters

A SOLUTION FOR EVERY APPLICATION

At different points of use, different compressed air purities might be needed, depending on the application. The various air purity classes are provided in the table below, which clearly shows the various Ingersoll Rand filters and dry at meet all the different classes.

G – Series     |     0.1 ppm (Oil)  & 1 micron (Particulate) Filter rating

H – Series     |     0.01 ppm (Oil) & 0.01 micron (Particulate) Filter rating

D – Series     |     1 micron (Particulate) Filter rating

A – Series     |      0.003 ppm (Oil Vapor – Carbon) Filter rating



PERFORMANCE & DIMENSIONS

  • Air System Design Capacity:  470 CFM @ 125 PSIG
  • Filtration Efficiency Rating:
    • Liquid Removal = 0.1 ppm
    • Particle Filtration = 1 micron
  • Inlet Pressure Range:  0-250 PSIG
  • Maximum Operating Pressure:  250 PSIG
  • Dimensions:  6.7″ L x 6.7″ W x 20.4″ H
  • Connection Size:  2″ NPT
  • Shipping Weight:  11.5 Lbs
  • ISO Certification
    • ISO 8573-2
    • ISO 12500
  • SKU Part # FA800IG

plz contact me for more information and exact price





Air Compressor Filters



Air Compressor Dryers

Refrigerated Dryers, Desiccant Dryers and filters; Air quality can have a significant impact on compressed air systems. Properly treated compressed air, and the right air dryer, will improve productivity, system efficiency, and product or process quality. Choosing the appropriate air dryer and compressed air filter is very important. By choosing an Ingersoll Rand air dryer or compressed air filter, you are buying high quality treatment products that will enhance your entire air compressor system. An air dryer is an integral piece in your air treatment system, making Ingersoll Rand's wide knowledge and expertise in this field a key aspect to the success of your compressed air system. Ingersoll Rand has the widest selection of air treatment products and application knowledge to protect your investment and compressed air system.



AIR TREATMENT

filters

Non-Cycling Refrigerated Dryers

Heatless Desiccant Dryers

Heated Desiccant Dryers

Cycling Refrigerated Dryers

HOC Desiccant Dryers

Non-Cycling Refrigerated Dryers 0.2-8 m3/min, 7-212 cfm

Capacity Range: 7-212 cfm (0.2-8 m3/min)

Pressure Dew Point: 38°F to 50°F (3°C to 10°C)

ISO Class 4 to 6

Cooling Method: Air-cooled

Voltage: 115/1/60, 230/1/50

Maximum Pressure: 203 psig (14 barg)

Maximum Ambient (air cooled): 122°F (50°C)

Maximum Inlet Temperature: 140°F (60°C)

Refrigerant: R-134A



FEATURES:

  • Reduced Energy Use: Efficient heat exchangers, a built-in stainless steel demister that removes all moisture and a fully adjustable programmable electronic drain valve reduce energy use and minimize air loss
  • Built-in Reliability: Corrosion-resistant heat exchangers, an enhanced control-system and high-efficiency moisture-separation ensure a steady long-term supply of dry air
  • Smart Control: Easy to use, advanced microprocessor control that lets you easily adjust and manage system parameters
  • Equipment Protection: Built-in coalescing filter stops contamination by separating water and oil from the compressed air
  • Consistent Clean, Dry Air: Variable-speed fans reduce power consumption when units operate at less than maximum cooling capacity, while ensuring a consistent dew point

F-Series Filters

F-Series advanced compressed air filters reduce contamination in your air stream to help protect critical processes and valuable equipment. Rigorously tested and engineered with superior components, F-Series filters will provide years of reliable performance and consistently high quality air.

Features:

  • Accurate Information: Patented dual indicator shows differential pressure drop and operating efficiency
  • Rugged Design: All-aluminum, precision die cast body suitable for 176 F / 80 C and 250 psig / 17.2 bar MAWP applications
  • Reliable Operation: Filter element with stainless steel mesh withstands high pressure and minimizes flow restriction
  • Easy Maintenance: Ergonomic bowl design with no-touch filter simplifies element replacement
  • Lone Element Life: Proprietary media coating technology protects against corrosion and increases element life




A

Patented dual indicator shows differential pressure drop and economical operating efficiency

B

Patented smooth bore flow insert directs air into the filter element, minimizing turbulence and pressure losses

C

All-aluminum, precision die cast body suitable for 80°C (176°F) and 17 bar g (250 psig)MAWP applications

D

Proprietary coating applied to the inside and outside surfaces provides corrosion protection in harsh industrial environments

E

Filter element with stainless steel mesh withstands high differential pressure while minimizing flow restriction through the element

F

Ergonomic bowl design with no-touch filter element simples element replacement

G

Time strip label indicates when it's time to change the element (A Grade only)

H

Industrial-grade brass float drain discharges accumulated condensate and oil more reliably than lesser quality plastic drains (no-loss and manual drains also available)

I

Deep-pleated filter media reduces air flow velocity to maximize filtration efficiency and minimize pressure losses

J

High-efficiency drainage layer improves liquid drainage properties and enhances chemical compatibility

K

Simple visual alignment of the filter head and bowl ensures accurate assembly of components and helps to improve safety



Specification

Filter model number Pipe sizeFlow rates
100psig/7 bar g
ModelGradeinm3/min
FA30IA, G, H, D3/8”0.4817
FA40IA, G, H, D1/2”0.6222
FA75IA, G, H, D3/4”1.2745
FA110IA, G, H, D3/4”1.8465
FA150IA, G, H, D1”2.4988
FA190IA, G, H, D1”3.12110
FA230IA, G, H, D1”3.82135
FA400IA, G, H, D1.5”6.66235
FA490IA, G, H, D1.5”8.21290
FA600IA, G, H, D2”9.91350
FA800IA, G, H, D2”13.3470
FA1000IA, G, H, D2”17600
FA1200IA, G, H, D3”20.1710
FA1560IA, G, H, D3”26.1920
FA1830IA, G, H, D3”30.61080
FA2300IA, G, H, D3”38.21350
FA2700IA, G, H, D3”45.31600
