1.Big heat sink: Will be better to guarantee the heat dissipation requirements;
2.Remote controlled: Kinds of colors and patterns for choice, flashing mode, motion speed are adustable;
3.Timer built-in:Run 6 hours and stop 18hours, circles in 24-hours period;
4.Easy to setup, adjust, and fix the angle of projection;
5. The housing color can be made in black or silver.
Specifications:
Model
ALB-RGB230-RM1
Dimensions(L*W*H)
240*135*155mm
Projection Coverage
Up to 5000 sq.ft@32ft away
Laser Classification
Class III/II
Laser Wavelength
Red-660 nm. Green-532 nm. Blue-450nm
Housing
Pure aluminum
Power Consumption
5W
Power Supply Input
100-240 VAC
Light Input
12V DC 0.5A
Operating Temperature
-26 to 35 ℃ (-22 to 86 ℉)
Waterproof Rating
IP 65
REMOTE CONTROL GENERAL INFORMATION
First, install the included 23A battery in the remote. To test the remote’s battery connection, press any button and the LED will illuminate for 1 second. If the LED does not illuminate, check to make sure you have installed battery according to the correct polarity.
REMOTE CONTROL FUNCTIONS: ON/OFF: Turns the device on & off COLOUR: Switches between colours ( Red / Green / Blue / Red & Green / Blue & Red / Blue & Green / then all 3 colours) Flash: Controls the speed at which the laser flashes (Slow, Medium, Fast or Static) Speed: Controls the speed at which the laser spins (Slow, Medium, Fast or Static). 2H: Turns the laser off after 2 hours of use. 4H: Turns the laser off after 4 hours of use.
6H: Turns the laser off after 6 hours of use. 8H: Turns the laser off after 8 hours of use. Timer reset: Turns on the timer function. Press before selecting the required time limit. If no time limit is set, the light will turn off after 6 hours.
