Полностью автоматическая машина для резки стекла и зеркала с ЧПУ воздушным плавающим

Полностью автоматическая машина для резки стекла и зеркала с ЧПУ воздушным плавающим

Категория: Машина по производству стекла >>>
Поставщик: Jinan,Artech,Machinery,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.92 $*	0.35 $*
Aug-15-2025	0.18 $*	0.58 $*
Jul-15-2025	0.75 $*	0.32 $*
Jun-15-2025	0.25 $*	0.54 $*
May-15-2025	0.46 $*	0.22 $*
Apr-15-2025	0.39 $*	0.62 $*
Mar-15-2025	0.81 $*	0.49 $*
Feb-15-2025	0.18 $*	0.33 $*
Jan-15-2025	0.0 $*	0.99 $*

Характеристики

Product Description

This machine use for glass cutting from 1-19 mm. It can meet the cutting requirements for different kinds of glass such as architectural glass, cosmetic mirror glass, furniture glass, spell mirror glass, round glass, watch glass, craft glass, etc.

\t Working area (X*Y)	\t 2500*2000mm (Can be customized)
\t Body structure	\t Thicken steel made
\t rails	\t Hiwin square rails
\t Cutting heads	\t 1 heads ( Can be customized 1-12 heads)
\t X, Y Resolution	\t <0.01mm
\t Max Moving Speed	\t 40000mm/min
\t XYZ traveling positioning accuracy	\t ±0.01mm
\t XYZ repositioning accuracy	\t ±0.01mm
\t Voltage	\t 3~380V 50HZ
\t Drive type	\t Leadshine stepper motors and drivers
\t Working Dictate	\t G Code,uoo,mmg,*plt
\t Operating system	\t NC-studio control system
\t Auto oil lubricator	\t included

Main Features

- Cutting pressure automatic adjusted according to glass thickness.
- Cutter head 360 degree rotating.
- Climbing wheels on the cutter head for protecting the cutter assembly and the glass.
- Water proof surface panel, stainless steel side covered, water and deformation resisting
- High quality felt, perfect level, anti-static
- Self-lubricating guide rail
- Air filter for keeping the oil clean
- Air float and belt transmit
- Linear guide rail
- Automatic oiling for transmission system

Option function
Glass automatic typesetting system:You just need to input the shape, dimension ,number ,system will automatic typesetting optimization.
Glass special-shaped automatic scanning system:You just need to put the samples of graphics on the machine table, the system will automatically scanning, and type-in the graphics into the computer.

Multi cutting heads: multi heads working at same time, improve the working efficiency

Sample picture

After sale Service

1. 12 months guarantee for whole machine from production date (except consumable parts) Within guarantee under normal use and maintenance, if something is wrong with the machine, you will get spare part for free.
2. Technical support by phone, email, whatsapp and Skype. Friendly English manual and operation video CD disk. Engineer available to service machinery overseas. You will also get technical support and service all the lifetime.
3. Normal machine is properly adjusted before dispatch. You will be able to use the machine immediately after received machine. You will be able to get free training advice toards our machine in our factory
