4K H.264 H.265 HD IPTV Encoder

Welcome to add my skype to get more details:Jacky.shineco

Outline

4K Encoder is a professional audio and video encoding products, which support 1 channel 4K HD video. dual streaming H.264/H.265 encoded output format, audio MP3, AAC formats. Can be freely adjusted according to the need. The device is highly integrated, cost-effective. Support UDP/RTP/HTTP / RTSP / RTMP/HLS transport protocols. Support for external audio input.

It is easy to install, plug-play, no need to disassemble the machines, and there is no hardware compatibility issues



Features:

•The embedded hardware encoding,

•Support 3840*2160/2560*1440/2048*1152/1920x1080p/1920x1080i/1280x720p

/720*576i/720*576p/640*480i solutions (customized)

•Support H.264 BASELINE PROFILE / MAIN PROFILE / HIGH PROFILE

• Support multiple devices display on a computer at the same time

•Support Smart Encoding format

•IP port with 1000M.

•Support audio gain.

• Support RTSP/RTMP, HTTP, UDP,HLS unicast, multicast and other protocols (RTMP supports adding the user and changing password )

• Support DHCP and Onvif protocol.

•Compatible with Wowza/FMS/RED5 streaming media server etc, work in with streaming media server to push the streaming , to achieve a live streaming

•Support Main TS stream and the sub TS stream  use in different network protocols ,Main Ts and Sub TS H.264/H.265 select respectively.for transmission (Multi-rate multi-protocol support)

•Rate Control :CBR / VBR 16KBIT / S ~ 50MBIT / S

• Video packaging: mode A: FFMPEG, mode B: VLC

• Support Output resolution by costom settings

•Transmission: TCP, UDP, 1000M (RJ45 Duplex network port)

•Support Add watermark(OSD),XY,Setting font

•Support WEB access in Chinese/English, passwords changing, WAN remote management (WEB)

•Support DHCP gaining IP automatic ,support One-key recovery, upgrade and remote maintenance

•support left and right sound channel

• Support one-key recovery of the default configuration

• Support set-top box decoder

• The low power consumption design

Specification

Product model	4K Encoder
Input	1 HD input
Output	1 channel IP signal output
Video	Input resolution	3840*2160/2048*1152/1920x1080p/1280x720p/720*576i/640*480i etc
	Coding standard	H.264/H.265
	Coding level	H.265 main profile        H.264 BASELINE PROFILE                                   H.264 MAIN PROFILE H.264 HIGH PROFILE
	Encoded size	640*360~3840*2160( customized)
	Video bit rate	Rate control: CBR/VBR 16KBIT/S~50MBIT/S
	Video frame rate	30/60
	OSD	Character ,images
Audio	Input selection	1 channel embedded audio HD, 1 channel 3.5MM independent audio  Support audio gain
	Audio coding	AAC/MP3
	Audio bit rate	24Kb/s~256Kb/s
	Sampling rate	32000,44100 etc
IP output	1 RJ 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol
System	Network protocol	Supports HTTP, RTSP, RTMP, UDP, HLSmulticast, unicast
	Configuration management	Support IE configuration, remote upgrade
The common use	Power supply	12V 2A
	power consumption	5W
	Size	102mm * 60mm *15mm(length*width*height)
	Operating temperature	-20℃+ 60℃
	Working humidity	<90%,Non-condensing
	Weight	0.1KG
Our company reserves the right to adjust the product parameters, if you have any questions please contact my skype:Jacky.shineco to check
