ceiling mounted hepa air purifier with clean room fan filter unit

Replacement Fan Filter Unit which draws in contaminated air from the top of the module, and exhausts filtered clean air vertically in a unidirectional(laminar) air stream at its base, is a self-contained fan and filter module for cleanroom applications.



Replacement Fan Filter Unit Features

• Nice appearance , human centered design--Adding stainless handle, easy installation and delivery, and perpendicular design.


• High performance and low noise fans--Adopting Energy-saving Multi-blade turbine fan, lower noise, Pressure spreads evenly, stable air velocity, low consumption, low running cost, service life can reach to longer than 80 thousand hours.


• Light, thin shape--Without filter net, thickness of shape is 23cm, 25KG weight, application in low ceiling are also available.


• Flexible, diversified design--Except for standard items, custom made FFU is available, such changings as filter nets, the materials of shell and etc...


• Concerning, convenient design---Pedals are designed in the body, which makes it convenient to install and repair.


• Premium Current-averaging design of the inside--Ensures deviation of the blowing side lower than ±10%.


•   Application: FFU’s are commonly used in the construction of Class 1 to Class 100,000 cleanrooms, even forming ultra clean line, clean closet and et.



 Terminal Fan Filter Specification and technical parameters

Model			FFU-1175		FFU-575	FFU-618
Dimension		mm	575*1175*320		575*575*320	615*615*320
air filter size		mm	575*1170*69		570*570*69	610*610*69
air Volume		m³/h	700-1800		350-900	350-950
External static pressure		Pa	98		98	98
Main body		-	Standard	cold rolled steel plate with powder coated
			Option	Stainless steel Galvanized steel Aluminum coated zinc plate SUPER GALUM
Power supply	Standard	V/Hz	220V 50Hz
	Option	V/Hz	Pls contact us if you have any other requirement about the power.
	Output poewr	W	140-150
Filter	Efficiency	-	HEPA Over 99.99% @ 0.3um
		-	ULPA Over 99.9995% @ 0.1um
	Frame	-	Aluminum
Shock		m/s2	≤0.4
Noise		Db(a)	≤55
Option		-	Differential draft gauge; Remote control; Duct flange for suction air; Pre-filter

 Special size can be customized.



Product show



 Q:Are you really manufacturer or trading company?
 A:We are indeed filter manufacturer over 17 years experiences and work with many brands for dozen years,such as Coke Cola,Pepsi,Sony,Zhongsheng Medicine and etc.



 Q:Where is the air filter generally use for?

 A:HAVC(Heating,air conditioning and ventilation system)Spray painting stop,chemical plant,pharmaceutical plant,cement or asphalt powder plant,clean room,power station,heavy and metal industry,Gas turbo and Co-generation utility plants, Engineering and devices plants, dry and bake room, Hospital,etc.



 Q:What's your testing standard?

 A:EN779:2012, ISO9001

Q:What is the international standard for air filter?

A:European and American use different name for the same standard.
Euro:Pre(G1-G4),Medium(F5-F9),HEPA(H10-H14),ULPA(U15-U17)
American:Pre(Merv1-7),Medium(Merv8-14),HEPA(Merv15-19),ULPA(Merv 20)
