3 роликовые Асимметричные гибочные ролл машина/конус и профиль рулонная

ü  THE MACHINE STRUCTURE

The machine has three roller, but the three roller is not symmetrical distributed, the upper roller is not in the middle above the two bottom rollers.

The upper roller is main drive roller making rotary movement. The bottom roller makes vertical movements to tight the plate, the output gear of the bottom roller is connected with the up roller’s input gear. Another one side roller make declining vertical movement.

This machine has a reliable divided mechanism structure to guarantee the synchronization of the three rollers when rolling at the same time. The bottom and the side roller’s vertical movement is controlled by lifting screw to achieve rolling different diameter.

The machine has pre-bending and rolling two function, this is best suitable machine for all 6MM thickness less plate rolling, can reach the same function compared with W12 four roller rolling machine. It can be used for high-precision of filmy plate and has high working efficiency.

ü  WORKING PRINCIPLE

1.         ROLLER 1 IS PINCHING ROLL ,IT IS CAPABLE TO PINCH T HE PLATE TIGHTLY.

2.         ROLLER 2 IS BACK SIDE BENDING ROLL ,WHICH IS CAPABLE TO ACT AS TWO FUNTION:ONE IS TO LEVEL THE PLATE ,SECOND IS TO ARRANGE THE PRE-BENDING FUNCTION. THROUGH THE THREE ROLLERS,THE PLATE WILL MAKE PERFECT BENDING ROLL WITH PRE-BENDING FUNCTION.

ü  STANDARD

THERE ARE TWO STANDARD FOR THE W11F SERIES 3 ROLLER BENDING ROLL MACHINE, PLEASE REVERT TO BELOW.

THE QUOTATION PAPER IS BASED ON STANDRD ONE.

STANDARD 1

1. Manual adjustment to Pinch Roll

2. Manual adjustment to Back Roll

3. Emergency Trip Wires

4.  Cone Bending

5. Brake Motor

6. Rolling Speed 15-17RPM Range

7. Hardness Rolls

8. Digital readout for position of back roll.

STANDRAD 2

1. Power To Back Roll

2. Power To Pinch Roll

3. Digital Read Out

4.Cone Rolling

5.Emergency Trip Wires

6. Brake Motor

7.Hardness Roll

8.Rolling Speed 15-17 RPM Range

9.Digital readout for position of back roll.
