Инверторная машина для плазменной резки

Месяц

Минимальная цена

Макс. стоимость

Sep-16-2025

7283.6 $*

7647.92 $*

Aug-16-2025

7222.27 $*

7583.65 $*

Jul-16-2025

6059.82 $*

6362.20 $*

Jun-16-2025

7099.43 $*

7454.86 $*

May-16-2025

6181.49 $*

6490.89 $*

Apr-16-2025

6977.98 $*

7326.16 $*

Mar-16-2025

6916.80 $*

7262.67 $*

Feb-16-2025

6854.91 $*

7197.85 $*

Jan-16-2025

6793.69 $*

7133.33 $*

Inverter IGBT Plasma Cutting Machine.

Product Description

1.Light and small.Simple operation, suitable for thin plate cutting.

2.convenient to cut stainless steel and other metal materials.

3.Clean cut, no frisbee, no need to polish, fast speed, low cost, stable and reliable.

Model parameters	CUT 60	CUT 100	CUT 160
input voltage(V)	AC380V±15%	AC380V±15%	AC380V±15%
frequency(Hz)	50/60	50/60	50/60
Rated input current(A)	13.5	26	44.3
Rated power(KVA)	8.9	17	29
Open circuit voltage(V)	295	268	307
Output current control(A)	20-60	20-100	20-160
Output current control(V)	104	120	144
Rated load duration.(%)	60	60	60
No-load loss(W)	60	80	80
Efficiency (%)	85	85	85
Power Factor	0.93	0.93	0.93
insulation grade	F	F	F
Enclosure protection class	IP21	IP21	IP21
Striking way	Contact arc	Non-contact arc	Non-contact arc
Recommended To Cut The Air Compressor Under Pressure(Kgf/cm2)	4-5	4-5	4-6
Cutting Thickness(mm)	1-20	1-35	1-40
Weight(kg)	35	38	62
Overall Dimensions(mm)	500×260×450	550×300×500	550×300×500
