Мощный электрический бесшумный Природный биогазовый генератор 250
- Категория: Генераторы газовых турбин >>>
- Поставщик: Camda,New,Energy,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.82 $* | 0.84 $* |
| Aug-19-2025 | 0.13 $* | 0.21 $* |
| Jul-19-2025 | 0.55 $* | 0.35 $* |
| Jun-19-2025 | 0.70 $* | 0.48 $* |
| May-19-2025 | 0.70 $* | 0.8 $* |
| Apr-19-2025 | 0.21 $* | 0.18 $* |
| Mar-19-2025 | 0.57 $* | 0.56 $* |
| Feb-19-2025 | 0.41 $* | 0.42 $* |
| Jan-19-2025 | 0.14 $* | 0.0 $* |
Характеристики
250 kw Power electric super silent natural biogas generator
biogas generator
GAS GENSET DATA | |
Genset model | KDGH250-BG |
Continuous power (kW/kVA) | 313/250 |
Connection type | 3 phases 4 wires |
Power factor cosfi | 0.8 lagging |
Voltage(V) | 415/240 |
Frequency (Hz) | 50 |
Rated current(Amps) | 434 |
Voltage Stabilized regulation | ≤±1.5% |
Voltage Instantaneous regulation | ≤±20% |
Voltage Recovery time (s) | ≤1 |
Voltage Fluctuation ratio | ≤1% |
Voltage Wave aberration ratio | ≤5% |
Frequency Stabilized regulation | ≤1%(adjustable) |
Frequency Instantaneous regulation | -10%~12% |
Frequency Fluctuation ratio | ≤1% |
Net weight(kg) | 4100 |
Genset dimension (mm) | 4200X1620X2300 |
Model | HGKT19 |
Type | 4 stroke, water-cooling, wet cylinder liner, electronic-control ignition system, pre-mixed perfect mixed burning |
Engine output | 336kW |
Cylinders& Arrangement | 6, line type |
Bore X Stroke(mm) | 159X159 |
Displacement(L) | 18.9 |
Compression ratio | 11:1 |
Speed | 1500RPM |
Aspiration | Turbocharged |
Cooling Method | Cogen/Water cooled by radiator |
Carburetor/gas mixer | Manual control(standard)/ Automatic control (option) |
Ignition controller | Altronic CD1 unit |
Firing order | 1-5-3-6-2-4 |
Governor type(speed regulating type) | Electronic governing, Huegli Tech |
butterfly valve | MOTORTECH |
Starting method | Electric, 24 V motor |
Idling speed(r/min) | 700 |
Gas consumption(m3/kWh) | 0.6 maximal |
Oil recommended | SAE 15W-40 CF4 or above |
Oil consumption | ≤0.5 g/kW.h |
