OEM Контроллер электрического пожарного насоса

Описание и отзывы

Трекер стоимости

Характеристики



Production Capacity:

PCB Item	Production Capacity
Layer Counts	1--20L
Base Material	FR4,High-TG FR4,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B)
Material Thickness(mm)	0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2
Max board size(mm)	1200x400mm
Board Outline Tolerance	±0.15mm
Board Thickness	0.4mm--3.2mm
Thickness Tolerance	±8%
Minimum line/space	0.1mm
SMD Pitch	0.3mm
Min  Hole Size(mechanical)	0.2mm
Min Hole Size(laser hole)	0.1mm
Hole Size Tol (+/-)	PTH:±0.075mm;NPTH: ±0.05mm
Surface Finish	HAL,ENIG,Plated Gold,Immersion Gold,OSP
Copper Weight	0.5--6oz
Solder mask	Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Acceptable File Format	Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000
Certificate	ROSH,ISO9001,UL



PCBA Item	Production Capability
PCB Assembly Service	SMT & PTH & BGA
Design Service	PCBA & enclosure design
Test	AOI, In-Circuit Test (ICT), Functional Test (FCT)
Other Service	Plastic injection molding; metal sheet stamping
SMT Capability
Lines	5 SMT lines
Capacity	50 million placements per month
Max Board Size	457*356mm.(18”X14”)
Min Component size	0201-54 sq.mm.(0.084 sq.inch),long connector,CSP,BGA,QFP
Speed	0.15 sec/chip,0.7 sec/QFP
PTH Capability
Lines	2 PTH lines
Max board width	400 mm
Type	Dual wave
Pbs status	Lead-free line support
Max temp	399 degree C

FAQ

1, What service do you have?

We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing  and other value-added service.



2, What is needed for PCB & PCBA quotation?

For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).

For PCBA: PCB information, BOM,Testing documents.



3. Are my design files secure when I send them to you?

Your files are never shared nor will any third parties have access to your design files. We can sign an NDA(Non-disclosure agreement) before sending files.



4. For small quantity orders, can you produce prototype PCBs?

Yes. DNC can produce prototypes. but the greater quantity, the greater cost saving.



5. What file formats do you accept for PCB and assembly?

Gerber ,CAM Auto CAD DXF, DWG formats.



6. Do you have after-sales product servicing available for your customers?

Yes, we supply one year warranty, for any quality problems DNC will take our responsibility to solve it for you any time.
