M12-3004PA PNP без 200mA 3 проволоки небольшой M12 Индуктивный бесконтактный датчик MIG MAG сварочный

Feature

Compact volume
high precision of repeated location
Diversified exterior structures
Good performance of anti-interference.
Many output forms
High on-off frequency.
Wide voltage range
Dust proof,vibration proof,water proof and oil proof.
With short-circuit protection and inverted connecting protection.
Long service life

Technical Parameter

Product Name: Capacitive Proximity Switch(Non-flush Type)
Material composition: metal plastic
Output form: DC NPN normally open

Detection distance:4mm

Working voltage:DC6-36V
Protection level: IP54
Output current: 200mA
Detectable objects: conductors and dielectrics

1. Switch category(LM: inductance type; CM: capactitance type;SM:Hall type; AM:safety explosion-proof type; XM: mimic linear type)

2. Outward appearance code(C: Cylinder type; F: Angular column type and planeinstall-ation type)

3. Operating voltage(30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC; 20:90-250VAC; 210:24-250VAC;220: 380VAC; 40: 12-240VDC/24-240AC; 50: Special voltage)

4. Detection distance( 01: 1mm; 05:5mm; 10:10mm)

5. Output method (N: Three-line DC NPN output;P: Three-line DC PNP output;L: Two-line DC output; AC two-wire output;J: Relay output;NP: NPN+PNP output)

6. Output status(A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current)

7. Auxi function code(T: With connector; Y: Water proof, oil proof; I: Special requirement;

H: High temp resistance; R: Ring type)
