Сварочный аппарат TIG 200A
US $152.00-$161.00
Самая продаваемая машина для сварки алюминия Sanyu
- Категория: Аппарат для аргонно-дуговой сварки >>>
- Поставщик: Shanghai,Sanyu,Industry,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 428.20 $* | 449.77 $* |
| Aug-17-2025 | 425.73 $* | 446.7 $* |
| Jul-17-2025 | 356.30 $* | 374.48 $* |
| Jun-17-2025 | 418.45 $* | 439.54 $* |
| May-17-2025 | 364.38 $* | 382.36 $* |
| Apr-17-2025 | 410.56 $* | 431.8 $* |
| Mar-17-2025 | 407.71 $* | 427.69 $* |
| Feb-17-2025 | 403.23 $* | 423.83 $* |
| Jan-17-2025 | 400.79 $* | 420.70 $* |
Характеристики
Sanyu Best Selling AC/DC Tig Aluminium Welding Machine
Company Information
Shanghai Sanyu is one of the leading AC drive, soft starter and welding machine manufactures and exporters in Shanghai China, which has about twenty years history in this field.
Till now our products have been exported to more than 30 countries.
Our inverter and soft starter were used in "Beijing Olympic Center, Shanghai Expo Pavilion, Shanghai Air Port" etc.
And we have CE, ISO9001, SGS, CCC certificate and so on.
We successfully developed AC drives as SY6600 series, SY7000 series, SY8000 Series and SY8600 series, soft starter as SJR2-2000 series economical type, SJR2-5000 intelligent type, SJR2-3000 built-in bypass type.
Product Description
Detailed specification of TIG AC/DC Pulse Aluminum argon welder
| Item/Model | TIG-200P | TIG-250P | TIG-315P |
| Voltage | 1-230V+/-10% | 1-230V+/-10% | 3-380V+/-10% |
| Frequency | 50/60HZ | 50/60HZ | 50/60HZ |
| No Load Voltage | 58V | 58V | 58V |
| Rated Input Power | 4.1Kw | 5.1Kw | 6.7Kw |
| Current Range | 10-200A | 10-250A | 20-315A |
| Rated Input Current | MMA:32.5 TIG:29.5 | MMA:36.5 TIG:31.5 | MMA:19.7 TIG:13.6 |
| Duty Cycle at 40℃ | 60% | 60% | 60% |
| Power factor | 0.73 | 0.73 | 0.93 |
| Pre-gas time(S) | 0.1~1 | 0.1~1 | 0.1~1 |
| Adjustment range of post-gas time(S) | 0.1~10 | 0.1~10 | 0.1~10 |
| Clearance effect(%) | -50~50 | -50~50 | -50~50 |
| IP | 21 | 21 | 21 |
| Efficiency | 85% | 85% | 85% |
| Insulation Class | F | F | F |
| Dimension | 375*155*232MM | 375*155*232MM | 375*155*232MM |
| Weight(kg) | 20 | 20 | 34 |
Fetures:
| 1. Adopt advanced IGBT inverter technology. | ||||
| 2.LED digital display. | ||||
| 3.2T/4T function is available. | ||||
| 4.Compact, portable, high effective and low consumption, energy saving. | ||||
| 5.With strong compensation capability, resistant to voltage fluctuation with stable welding current. | ||||
| 6.Pulse TIG/MMA AC/DC functions. | ||||
| 7.High frequency arc-starting. | ||||
| 8.DC function can be used in welding various nonferrous, metals, stainless steel, alloy steel, carbon steel and copper. | ||||
| 9. AC function can be used in welding Aluminum and Aluminum alloy. | ||||
| 10. Complete accessories--TIG torch, electrode holder, earth clamp with cable, carton box. |
Certificates we have of TIG AC/DC Pulse Aluminum welding machine
Service
