Product Description

Car Body Recycling Crusher Machine


Car body recycling crusher machine is my company combined with the international advanced technology development and the formation of a new generation of products. There are five models: HY-1300, HY-1600, HY-1800, HY-2000, HY-2200. Our car body recycling  crusher machine  not only improves the production capacity, crushing efficiency, but also expand the scope of application.

Car body recycling crusher machine produced by our company is an advanced crushing and smashing machine. The series of  products have fully developed the theories of impact, shearing, mutual strike and grinding on the basis of absorbing the advantages of various grinders.

My company  car body recycling crusher machine  targets: the width of not more than 1.7 meters of the car shell, scrap metal, Caigangwa, household appliances shell, motorcycle electric frame and within 80 kg of metal briquetting, ring-up cans within 100 kg , paint buckets etc. Yield of not less than 10 tons per hour.

This kind of  car body recycling  crusher machine standard can reach the state-approved environmental-friendly machine standard, which can fully realize the value of waste materials recycling.

Production Process:
Conveying - Metal crusher - Discharge delivery - Magnetic separation - Dosing - Dust removal - PLC full control


If you have you any time, please contact us.                         What's app/We chat:+0086 18039505731




\t
Parameter of machine
\t
No.
\t
Item detail
\t
HY-1300
\t
HY-1600
\t
1
\t
Sheller's thickness
\t
40mm
\t
40mm
\t
2
\t
Sleeve thickness
\t
30mm
\t
30mm
\t
3
\t
Disc plate
\t
Dia:800mm
Thickness:100mm
\t
Dia:1100mm
Thickness:100mm
\t
4
\t
Screen plate
\t
Thickness:80mm,
Hole:50-100mm

\t
Thickness:110mm,
Hole:50-100mm
\t
5
\t
Hammer
\t
Cr-alloy
38/pcs
\t
Materials:Cr-alloy
48kg/pcs
\t
6
\t
Rotary axis
\t
Dia:230mm
Cr42

\t
Dia:260mm
Cr42
\t
7
\t
Motor
\t
110kw*2ets
6grade
\t
180kw*2sets,6grade
\t
8
\t
Feeding conveyo
\t
W:1.1m, L:14m
\t
Width:1.1m, Length:14m
\t
9
\t
Belt conveyor
\t
W:0.5m, L:6m,2ets
\t
Width:0.5m, Lenght:6m,2ets
\t
10
\t
Magnetic belt conveyor
\t
W:0.5m, L:6m, 1set
\t
Width:0.5m, Length:6m, 1set
\t
11
\t
Electricity control box
\t
Fully automatic conveyor box
\t
Fully automatic conveyor box
\t
12
\t
Total Power
\t
250kw
\t
400kw
\t
13
\t
Total weight
\t
23Ton
\t
32Ton

After the Metal steel shredder machine products have the following advantages:


1. neat shape, similar specifications, increasing the volume ratio;
2. there is a higher proportion of heap, reducing transportation costs;
3. fewer attachments, removing paint debris;
4. higher purity, increasing melting rate;

Semi-finish products
Characteristics

The use of crushed steel for steel smelting has the following advantages:
1. high yield;
2. the chemical composition of molten steel is stable, low phosphorus content;
3. smelting cycle shortened;
4.furnace lining life extension;
5. air pollution and slag reduction;
6.power consumption per ton of molten steel reduced

For scrap recycling companies that the use of  car body recycling  crusher machine processing and recycling.

advantages:
1. expanding the scope of processing and recycling;
2. high value space;
3. transport convenient and efficient

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
