Система испарительного конденсатора закрытая башня водяного

Evaporator Condenser System Closed Water Cooling Tower is one of the most important parts of the whole refrigeration system. The condenser condenses the refrigerant gas inside the coil and complete a heat exchange circle. The evaporative condenser is widely applied to cold storage, ice-store, chemical industry, supermarket and etc.

Model	Heat Rejection(KW)	Size(L*W*H) mm	Weight(kg)	Fans  (Air Flow  m3/hr)	Water Pump  (Water Flow  L/S)
ECE300	305	2100*1245*3080	1800	30000	6.2
ECE350	356	2100*1420*3080	1960	30000	6.2
ECE400	405	2100*1590*3080	2130	50000	6.2
ECE450	455	2100*1790*3080	2300	50000	7
ECE500	506	2100*1960*3080	2460	50000	7
ECE550	555	2170*2100*3080	2630	50000	7
ECE600	605	2400*2100*3180	2950	60000	12.4
ECE650	659	2570*2100*3180	3120	60000	12.4
ECE700	706	2740*2100*3180	3310	75000	12.4
ECE750	755	2915*2100*3180	3500	75000	13.9
ECE800	805	3085*2100*3180	3670	75000	13.9
ECE850	856	3285*2100*3180	3840	75000	13.9
ECE900	906	3485*2100*3230	4100	90000	24.7
ECE950	959	3655*2100*3230	4270	90000	24.7
ECE1000	1005	3825*2100*3230	4400	90000	24.7
ECE1050	1056	4065*2100*3230	4610	90000	24.7
ECE1100	1109	4235*2100*3230	4930	120000	24.7
ECE1150	1156	4405*2100*3230	5100	120000	24.7
ECE1200	1206	4575*2100*3230	5280	120000	24.7
ECE1250	1259	4775*2100*3280	5450	120000	24.7
ECE1300	1305	4975*2100*3280	5615	120000	24.7
ECE1400	1406	5345*2100*3280	5960	120000	24.7
ECE1500	1509	5690*2100*3280	6390	150000	27.8

Main Features  (Evaporator Condenser System Closed Water Cooling Tower)

(1) Power-saving; Water-saving; Space-saving
(2) High Heat Exchange Ability
(3) Easy to instal
(4) Low maintenance cost
(5) Long lifetime

Evaporator Condenser System Closed Water Cooling Tower

Design & Features
