Характеристики


Pruduct Show
Specification
\t
Item name
\t
P8 P10 Outdoor Multi Color Advertising Digital LED Billboard
\t
Size
\t
customized
\t
Structure material
\t
steel
\t
Cladding material
\t
galvanized plate
\t
LED screen
\t
P8
\t
Surface finished
\t
hot dip galvanized/powder coated/painting
\t
Packing
\t
wooden case
\t
OEM service
\t
yes
LED Screen Data
\t
1. LEDs Data
\t
Chips brand:
\t
Epistar
\t
LED Type :
\t
SMD
\t
Brightness :
\t
≥ 6000 nits
\t
Viewing Angle :
\t
120°(H) / 60°(V)
\t
2. Module Data
\t
Pitch :
\t
8 mm
\t
Resolution :
\t
32 x16 dots
\t
Size :
\t
256mm x 128mm
\t
Pixel Density :
\t
15625 dots/m² (real pixels)
\t
Driving Mode :
\t
1/4 scan
\t
3. Cabinet Data
\t
Depth :
\t
150 mm
\t
Material :
\t
steel
\t
Maintenance :
\t
Fixed Back-access
\t
Weight :
\t
approx.45 kg per cabinet
\t
4. Screen Data
\t
Driving IC :
\t
MBI 5020/5024/5124/16126/2026/16106......
\t
Power Supply :
\t
Chenglian with CE&Rohs certificates AC110V/AC220V 50-60Hz
\t
Max Power Consumption:
\t
≤800W/㎡
\t
Average Consumption:
\t
500W/㎡
\t
Protection Level:
\t
IP65
\t
Refresh Rate:
\t
1000HZ
\t
Best View Distance:
\t
8-200 m
\t
Surface Flatness :
\t
GAP< 0.5 mm
\t
Screen Certificates:
\t
CE &Rohs
\t
Screen Controllers :
\t
Linsn,Nova,Dbstar,Zdec, popular asynchronous controllers
\t
Frame Update Frequency:
\t
50- 60Hz
\t
Gray Scale:
\t
14 bits input
\t
Display Color:
\t
10 trillion
\t
Brightness Adjustment:
\t
256 Levels with RGB individual adjustment
\t
Control Mode:
\t
Synchronous display with control PC by DVI / Asynchronous
\t
Gamma Correction:
\t
16 bits
\t
Support Input:
\t
Composite Video,S-Video,DVI,CATV,Popular Formats of Pics
\t
Control Distance:
\t
Ethernet Cable 100m,Single-model fiber 5km
\t
Support VGA Mode:
\t
800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200,
\t
Brightness Correction :
\t
Dot by Dot, module by module, cabinet by cabinet
\t
Operating Temp :
\t
- 35°~ +60° Celsius degree
\t
Storaging Temp :
\t
- 35°~ +80° Celsius degree
\t
Operating Humidity :
\t
10 - 90 % RH
\t
Operating Life :
\t
100000 Hours
\t
Continuous Working Time :
\t
≥48 hrs
\t
MTBF :
\t
10000 Hours
\t
Loss Control Pixel Rate :
\t
0.1‰
Production
Cases
Factory

YEROO Group Co., Ltd. established in 2000, with three subsidiary companies, "Foshan YEROO Advertising Engineering Co., Ltd", " Guangzhou YEROO Steel Structure Co., Ltd" and "Guangzhou YEROO Tech Co., Ltd", is a leading company which integrates industrial and trade in production, research and development, and sales of metal plate, steel structure products, and LCD electronic products.

YEROO specialized in research and development of outdoor advertising products which is stretching from large scale light box, billboard, bus shelter, scrolling light boxes, solar energy light box and LCD display with 17-year experience. Our products have been well exported to Mid East, South Asia, Africa, North America, South America, Oceania, more than sixty countries. We have successively participated various domestic and foreign sign exhibitions in Dubai, Russia, Germany, South Africa, Guangzhou and Shanghai.
Customer trust and reputation is the guarantee of our brand. We are constantly improving to become a better YEROO.
Foshan YEROO Advertising Engineering Co.,Ltd has more than 12,000 square meters of plants, with a strong production, design research and development , and sales service team.
YEROO Group strengthens its own advantages continually, to build a solid and lasting cooperation bridge with customers, base on the principle of safety, integrity, innovation, win-win spirit, good products, and good service.
