Профессиональный Многофункциональный Интеллектуальный ручной анализатор проводных кабелей Netwoek тестер VDSL/
- Категория: >>>
- Поставщик: Beijing,Byx,Optical,Fiber,Cable,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.94 $* | 0.21 $* |
| Aug-19-2025 | 0.42 $* | 0.50 $* |
| Jul-19-2025 | 0.43 $* | 0.85 $* |
| Jun-19-2025 | 0.2 $* | 0.1 $* |
| May-19-2025 | 0.5 $* | 0.1 $* |
| Apr-19-2025 | 0.48 $* | 0.80 $* |
| Mar-19-2025 | 0.55 $* | 0.11 $* |
| Feb-19-2025 | 0.71 $* | 0.92 $* |
| Jan-19-2025 | 0.73 $* | 0.23 $* |
Характеристики
1.Specifications
| ADSL2+ | |
| Standards | ITU G.992.1(G.dmt),ITU G.992.2(G.lite), |
ITU G.994.1(G.hs),ANSI T1.413 issue #2,ITU G.992.5(ADSL2+) Annex L | |
| Up channel rate | 0~1.2Mbps |
| Down channel rate | 0~24Mbps |
| Up/Down attenuation | 0~63.5dB |
| Up/Down noise margin | 0~32dB |
| Output power | Available |
| Error test | CRC, FEC, HEC, NCD, LOS |
| Display DSL connect mode | Available |
| Display channel bit map | Available |
| ADSL | |
| Standards | ITU G.992.1 (G.dmt), ITU G.992.2(G.lite), |
| ITU G.994.1(G.hs), ANSI T1.413 Issue # 2 | |
| Up channel rate | 0~1Mbps |
| Down channel rate | 0~8Mbps |
| Up/Down attenuation | 0~63.5dB |
| Up/Down noise margin | 0~32dB |
| Output power | Available |
| Error test | CRC, FEC, HEC, NCD, LOS |
| Display DSL connect mode | Available |
| Display channel bit map | Available |
| DMM Test | |
| DC voltage (V): | 0~400 |
| AC voltage (V): | 0~400 |
| Loop resistance(Ω): | 0~20000 |
| Capacitance (nF): | 0~1000 |
| Insulation resistance (MΩ): | 0~50 |
| Optical Power Meter ( Optional) | |
| Measurement range: | -70~+10dBm or -50~+26dBm |
| Wavelength | 850nm,1300nm,1310nm,1490nm,1550nm,1625nm |
| Visual Fault Locator (Optional) | |
| Output Power | 10mw |
| Wavelength | 650nm ± 20nm |
| Tone Tracker (Optional) | |
| Output Power | 10mw |
| Wavelength | 650nm ± 20nm |
| TDR Function (Optional)-Auto Test the cable fault distance (Cable Break/ Cable Mix) | |
| Test Range | <2.5km |
| Dead Zone | <1m |
| Resolution Rate | 1m |
2. Key Features
Ø Test objects: ADSL; ADSL2; ADSL2+; READSL; VDSL2
Ø Fast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance)
Ø Supports Modem emulation and simulating login to Internet
Ø Supports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test)
Ø Supports all multi-protocol, PPPoE / PPPoA (LLC or VC-MUX)
Ø Connects to CO via alligator clip or RJ11
Ø Rechargeable Li-ion Battery
Ø Beep and LEDs alarm indications (Lower Power, PPP, LAN,xDSL)
Ø Data memory fuction
Ø LCD display, Menu operation
Ø Auto shut off if no any operation on keyboard
Ø Compliant with all known DSLAMs
Ø Software management
Ø Simple, portable and money-saved
3. Functions
Ø DSL Physical layer test
Ø Modem Emulation (Replace the user Modem completely)
Ø PPPoE Dialing (RFC1683,RFC2684,RFC2516)
Ø PPPoA Dialing (RFC2364)
Ø Telephone Function
Ø DMM Test
Ø Ping Function (WAN & LAN)
Ø Data upload to computer and software management
Ø Setup system parameter: backlight time, shut off automatically time without operation, press tone,
Ø Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.
Ø Check dangerous voltage
Ø Optical Power Meter (Optional)
Ø Visual Fault Locator (Optional)
Ø Tone Tracker (Optional)
Ø TDR Cable Fault Locator (Optional)
